Subaru Impreza GK2 (2016-2019) main microcomputer Wiring diagrams
This page contains all the electrical diagrams for the component. main microcomputer, in which he is found in the car Subaru Impreza GK2 (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram main microcomputer (1 of 2)
AWD IND
BEHIND STEERING WHEEL)
BLK WIRE
BLU WIRE
BRN WIRE
CAN TRANSCEIVER, RECEIVER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSTANT VOLTAGE CIRCUIT
CVT/ATF TEMPERATURE IND
DIMMER
DRIVE CIRCUIT
ENGINE COOLANT TEMPERATURE IND
ENGINE COOLANT TEMPERATURE WARNING IND
FROM DRIVER'S SEAT BELT IND (DIAGRAM 1 OF 3)
FUSE 26
GB-2
GB-4
GRN WIRE
GRY WIRE
HIGH GRADE MFD
HILL START ASSIST OFF/ HILL START ASSIST
HOT AT ALL TIMES
LCD
LEFT TURN SIGNAL IND
LOW FUEL LEVEL IND
LOW OIL LEVEL IND
MAIN MICROCOMPUTER
MALFUNCTION IND
MFD
MICROCOMPUTER
NCA WIRE
OIL PRESSURE IND
PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B)
RED WIRE
RIGHT TURN SIGNAL IND
ROLL CONNECTOR
SATELLITE SWITCH
STANDARD MFD
Go to component -> Instrument cluster circuit, normal meter (3 of 3) -> MAIN MICROCOMPUTER
Wiring diagram main microcomputer (2 of 2)
BEHIND STEERING WHEEL)
BLK WIRE
BLU WIRE
BRN WIRE
CAN TRANSCEIVER, RECEIVER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSTANT VOLTAGE CIRCUIT
DIMMER
DOWN
DRIVE CIRCUIT
FROM DRIVER'S SEAT BELT IND (DIAGRAM 1 OF 3)
FUSE 26
GB-2
GB-4
GRN WIRE
GRY WIRE
HI-BEAM IND
HIGH GRADE MFD
HILL START ASSIST OFF/ HILL START ASSIST
HOT AT ALL TIMES
I/SET
LCD
LEFT TURN SIGNAL IND
MAIN MICROCOMPUTER
MFD
MICROCOMPUTER
NCA WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B)
RED WIRE
RIGHT TURN SIGNAL IND
ROLL CONNECTOR
SATELLITE SWITCH
SECURITY IND
SPEAKER
STANDARD MFD
STEERING SWITCH
Go to component -> Instrument cluster circuit, tft meter (3 of 3) -> MAIN MICROCOMPUTER
