Instrument illumination circuit for Subaru Impreza GD/GC/GG facelift (2002-2005)

AT SELECT LEVER ILLUMINATION LIGHT BLK WIRE BLK/WHT WIRE BLU WIRE CLOCK COMBINATION METER COMBINATION SWITCH LIGHT SWITCH COMPACT DISC PLAYER ILLUMINATION LIGHT CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT DIMMER CIRCUIT ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) EXCEPT WRX FRONT ACCESSORY POWER SUPPLY SOCKET ILLUMINATION LIGHT FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT FUSE 12 FUSE 13 FUSE 7 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GB-3 (NEAR BOTTOM OF "A" PILLAR) GB-4 (BEHIND RIGHT SIDE OF DASHBOARD) GLOVE BOX ILLUMINATION LIGHT GRN/YEL WIRE GRY/RED WIRE HAZARD SWITCH ILLUMINATION LIGHT HEAD HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION LIGHTS INTEGRATED MODULE (BEHIND LEFT SIDE OF DASH) MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPARTMENT) MODE CONTROL PANEL ILLUMINATION LIGHT NCA WIRE ODO/TRIP LCD BACKLIGHT OFF ORG/ WIRE ORG/WHT WIRE OUT TEMP LCD BACKLIGHT PARK PNK/BLU WIRE RADIO ILLUMINATION LIGHT RED WIRE RED/WHT WIRE TAIL AND ILLUMINATION RELAY VIO WIRE WHT WIRE WHT/RED WIRE WRX
