Courtesy lamps circuit for Subaru Impreza GD/GC/GG facelift (2002-2005)

BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE COMBINATION METER DIODE (WAGON) DOOR DOOR WARNING LIGHT FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GB-3 (NEAR BOTTOM OF "A" PILLAR) GB-4 (BEHIND RIGHT SIDE OF DASHBOARD) GB-6 (UNDER LEFT FRONT OF CENTER CONSOLE) GB-7 (BEHIND CENTER OF DASHBOARD) GB-8 (NEAR LICENSE PLATE LIGHT) GB-8 (RIGHT REAR END OF VEHICLE) HOT AT ALL TIMES MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPARTMENT) FUSE 2 INTEGRATED MODULE (BEHIND LEFT SIDE OF DASH) KEY ILLUMINATION LIGHT LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LUGGAGE ROOM LIGHT (WAGON) LUGGAGE ROOM LIGHT DIODE (WAGON) OFF ON DOOR OFF ORG/ WIRE REAR GATE LATCH SWITCH (WAGON) RED WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH ROOM LIGHT SEDAN SPOT LIGHT TRUNK ROOM LIGHT (SEDAN) TRUNK ROOM LIGHT SWITCH (SEDAN) WAGON YEL WIRE YEL/BLK WIRE YEL/RED WIRE
