Subaru Impreza GD/GC/GG facelift (2002-2005) speedo- meter circuit tacho- meter Wiring diagram

A/C SYSTEM BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMBINATION METER COOLING FANS SYSTEM CUSTOM CPU DEFOGGER SYSTEM DIAGNOSIS CONNECTOR (BEHIND LEFT SIDE OF DASH) DK GRN/WHT WIRE ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) EXTERIOR LIGHTS, POWER WINDOWS SYSTEMS FUEL INJECTORS FUSE 5 FUSE SBF-5 GB-3 (BOTTOM OF "A" PILLAR) GE (RIGHT REAR OF ENG) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES IDLE AIR CONTROL SOLENOID VALVE (ON FRONT OF ENGINE) IGNITION COIL, IGNITOR (TOP FRONT OF ENG) INTERNAL PRESSURE SOLENOID VALVE LINE END CONNECTOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE BOX MAL- FUNCTION INDICATOR LAMP ORG/ WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/GRN WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SHIELDED SPEEDO- METER CIRCUIT TACHO- METER TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
