Subaru Impreza GD/GC/GG facelift (2002-2005) remote control rearview mirror switch Wiring diagram
This page shows the only wiring diagram for the component.remote control rearview mirror switch, which is found in the car Subaru Impreza GD/GC/GG facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote control rearview mirror switch (1 of 1)
BLK WIRE
BLU WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
FUSE 4
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-3 (NEAR BOTTOM OF "A" PILLAR)
GRN WIRE
HOT IN ACC OR ON
LEFT REARVIEW MIRROR
LEFT/ RIGHT MOTOR LEFT/ RIGHT MOTOR
MIRROR HEATER
NCA WIRE
RED WIRE
REMOTE CONTROL REARVIEW MIRROR SWITCH
RIGHT REARVIEW MIRROR
UP/ DOWN MOTOR
W/ HEATED MIRRORS W/O HEATED MIRRORS
YEL WIRE
Go to component -> Power mirrors circuit -> REMOTE CONTROL REARVIEW MIRROR SWITCH
