Subaru Impreza GD/GC/GG facelift (2002-2005) rear accessory socket fuse holder fuse Wiring diagram
This page shows the only wiring diagram for the component.rear accessory socket fuse holder fuse, which is found in the car Subaru Impreza GD/GC/GG facelift (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear accessory socket fuse holder fuse (1 of 1)
ACCESSORY RELAY (BEHIND LEFT SIDE OF DASH, IN RELAY BLOCK)
BLK WIRE
BLU WIRE
GB-5 (BEHIND CENTER OF DASHBOARD)
GB-6 (UNDER LEFT FRONT OF CENTER CONSOLE)
GRN WIRE
GRN/BLK WIRE
HIGH OFF LOW
HOT AT ALL TIMES SBF-2 FUSE
HOT IN ACC OR ON FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 4
LEFT SEAT HEATER
LEFT SEAT HEATER SWITCH
MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT)
REAR ACCESSORY POWER SOCKET
REAR ACCESSORY SOCKET FUSE HOLDER FUSE
RED WIRE
RED/BLK WIRE
RIGHT SEAT HEATER
RIGHT SEAT HEATER SWITCH
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Power seats circuit -> REAR ACCESSORY SOCKET FUSE HOLDER FUSE
