Transmission circuit for Subaru Impreza GD/GC/GG facelift 2 (2005-2007)

A/T OIL TEMP IND AWD IND BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION METER SPEEDO- METER COMPUTER DATA LINES SYSTEM DIMMER CIRCUIT GB-3 GB-4 (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE INHIBITOR SWITCH (RIGHT SIDE OF TRNSMISSION) LT GRN WIRE LT GRN/BLK WIRE MICRO COMPUTER NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TORQUE CONVERTER TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH) TURBINE SPEED SENSOR VEHICLE SPEED SENSOR #1 VEHICLE SPEED SENSOR 2 (AWD) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

2-4 BRAKE A/T CONTROL (TRANSMISSION) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BODY INTEGRATED MODULE (BEHIND LEFT SIDE BRN WIRE COMPUTER DATA LINES SYSTEM DUTY DUTY SOLENOID ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUSE 13 FUSE 16 FUSE 4 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) FUSE 11 FWD SWITCH (AWD) GB-1 (RIGHT SIDE OF ENGINE COMP) GB-5 (BEHIND CENTER OF DASH) GRN WIRE GRN/RED WIRE GRY WIRE HIGH CLUTCH DUTY HOT AT ALL TIMES HOT AT ALL TIMES MAIN FUSE BOX (M/B) (ON LEFT SIDE OF ENGINE COMPT) FUSE 4 HOT IN ON OR ACC HOT IN ON OR START LINEAR SOLENOID LINE PRESSURE LOCK-UP DUTY LOW CLUTCH LOW, REVERSE LT BLU WIRE LT GRN/BLK WIRE LT GRN/RED WIRE OF DASH) ORG/ WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RELAY HOLDER SENSOR ATF TEMPERATURE SHIFT LOCK DIODE (BEHIND LEFT SIDE OF DASH) SHIFT LOCK SOLENOID TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH) VIO WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
