Anti-lock brake circuits for Subaru Impreza GC/GF (1992-2000)

ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ABS G SENSOR (LEFT REAR OF ENGINE COMPT) ABS INDICATOR BLK WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE CHECK CONNECTOR (BEHIND CENTER OF DASH) COMBINATION METER DATA LINK CONNECTOR (RIGHT OF STEERING COLUMN) DIAGNOSIS CONNECTOR (RIGHT OF STEERING COLUMN) (FRONT OF RIGHT FRONT FENDER) FUSE 14 FUSE 16 FUSE 18 FUSE 8 FUSE/ RELAY BOX GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES SBF HOLDER SBF-7 FUSE HOT IN RUN OR START LEFT FRONT ABS SENSOR LEFT REAR ABS SENSOR LT GRN/RED WIRE LT GRN/YEL WIRE NCA WIRE PNK WIRE RED WIRE RED/YEL WIRE RIGHT FRONT ABS SENSOR RIGHT REAR ABS SENSOR SHIELD JOINT CONNECTOR (LEFT SIDE OF ENG COMPT) STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) W/ CRUISE W/O CRUISE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL/GRN WIRE
