Subaru Forester SK facelift (2021-2024) tft back ind Wiring diagram
This page shows the only wiring diagram for the component.tft back ind, which is found in the car Subaru Forester SK facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tft back ind (1 of 1)
AUTO
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT (LEFT END OF DASH)
BRIGHT SWITCH
BRN WIRE
CAN L
CAN TRANSCEIVER
CIRCUIT
CLEARANCE
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DIMMER
DRIVE
DRIVE CIRCUIT
GB-10 (LEFT SIDE OF RADIATOR SUPPORT)
GB-4 (LEFT KICK PANEL)
GB-9 (RIGHT RADIATOR SUPPORT)
GRN WIRE
GRY WIRE
IGN
ILLUMINATION CONTROL SWITCH
ILU
INDICATOR NEEDLE ILLUMINATION LIGHT
INDIRECT LIGHTING
LCD BACK LIGHT
LEFT FRONT COMBINATION LIGHT
LGT SW
LIGHTING SWITCH
LT BLU WIRE
MICROCOMPUTER
NCA WIRE
OFF
PLATE ILLUMINATION LIGHT
PNK WIRE
POWER
RED WIRE
RIGHT FRONT COMBINATION LIGHT
SIDE MARKER
TFT BACK IND
VIO WIRE
W/ LED
W/O LED
WHT WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> TFT BACK IND
