Subaru Forester SK facelift (2021-2024) rear differential oil temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.rear differential oil temperature sensor, which is found in the car Subaru Forester SK facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear differential oil temperature sensor (1 of 1)
AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION)
AVH SW
AVH/EPB CONTROL SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SWITCH
BRN/YEL WIRE
CAN L
COMPUTER DATA LINES SYSTEM
EPB ON IND
FLUID
FUSE 10
FUSE 14
FUSE 29
FUSE 3
FUSE 30
FUSE 36
FUSE 9
FUSE, RELAY BOX (F/B)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
HOT W/ IG 1 RELAY ENERGIZED
HOT W/ IG 2 RELAY ENERGIZED
IGN
IND
KEY WARNING SWITCH
LEVEL
LOCK
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
MAIN FUSE BOX (M/B)
OIL PRESSURE SWITCH
PNK WIRE
PNK/GRN WIRE
REAR DIFFERENTIAL OIL TEMPERATURE SENSOR
RED WIRE
RELEASE
SW 1
SW 2
SW 3
SW 4
TAN WIRE
VDC CONTROL MODULE
VIO WIRE
W/ COLOR TFT METER
W/ CONSOLE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Instrument cluster circuit (2 of 4) -> REAR DIFFERENTIAL OIL TEMPERATURE SENSOR
