Subaru Forester SK facelift (2021-2024) left remote control back rest switch Wiring diagram
This page shows the only wiring diagram for the component.left remote control back rest switch, which is found in the car Subaru Forester SK facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left remote control back rest switch (1 of 1)
A/C CONTROL PANEL
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
DOOR LOCK BACKUP UNIT
FROM DC/DC CONVERTER 1 (DIAGRAM 2 OF 8)
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 7 OF 8)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 8)
FRONT LOCK RELAY
FRONT UNLOCK RELAY
FUSE 25
FUSE 31
FUSE 35
FUSE, RELAY BOX (F/B)
GB-4
GRN WIRE
KEYLESS ACCESS CONTROL MODULE
LEFT FRONT POWER WINDOW MOTOR
LEFT POWER SEAT
LEFT POWER SEAT SWITCH
LEFT REAR POWER WINDOW MOTOR
LEFT REMOTE CONTROL BACK REST SWITCH
N/A
PNK WIRE
POWER REAR GATE CONTROL MODULE
POWER SEAT, REMOTE CONTROL MIRROR CONTROL MODULE
POWER WINDOW CIRCUIT BREAKER
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
REAR GATE UNLOCK RELAY
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT POWER SEAT (W/O MEMORY)
RIGHT POWER SEAT SWITCH
RIGHT REAR POWER WINDOW MOTOR
RIGHT REMOTE CONTROL BACK REST SWITCH
SUNROOF UNIT
TAN WIRE
W/ DRIVER'S SEAT OFF DELAY FUNCTION
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 8) -> LEFT REMOTE CONTROL BACK REST SWITCH
