Subaru Forester SK facelift (2021-2024) control unit) Wiring diagrams

This page contains all the electrical diagrams for the component. control unit), in which he is found in the car Subaru Forester SK facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

control unit) wiring diagram (1 of 5)

AUTO SWITCH BLK WIRE BLK/WHT WIRE BLU WIRE BODY INTEGRATED UNIT CONTROL UNIT) DOWN DRIVER'S SIDE DRIVING UNIT FUSE 3 FUSE, RELAY BOX (F/B) GB-2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED LEFT FRONT POWER WINDOW MOTOR LOCK LT BLU WIRE MAIN FUSE BOX (M/B) OFF PNK WIRE POWER WINDOW CIRCUIT BREAKER POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW RELAY POWER WINDOW SWITCH CONTROLLER RED WIRE RIGHT END OF DASH) SBF-5 FUSE SWITCH ILLUMINATION LIGHT TAN WIRE UNLOCK VIO WIRE WHT WIRE

Go to component -> Power windows circuit, w/ all seats off delay function (1 of 2) -> CONTROL UNIT)

control unit) wiring diagram (2 of 5)

AUTO AUTO UP BLK WIRE BLU WIRE BRN WIRE CONTROL UNIT) DOWN DRIVING UNIT FRONT POWER WINDOW SUB SWITCH GB-6 GB-8 GRN WIRE GRY WIRE LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LT BLU WIRE OFF RED WIRE RIGHT FRONT POWER WINDOW MOTOR RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power windows circuit, w/ all seats off delay function (2 of 2) -> CONTROL UNIT)

control unit) wiring diagram (3 of 5)

AUTO SWITCH BLK WIRE BLK/WHT WIRE BLU WIRE BODY INTEGRATED UNIT BRN WIRE CONTROL UNIT) DOWN DRIVER'S SIDE DRIVING UNIT FUSE 3 FUSE, RELAY BOX (F/B) GB-2 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT POWER WINDOW MOTOR LOCK LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) OFF PNK WIRE POWER WINDOW CIRCUIT BREAKER POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW RELAY POWER WINDOW SWITCH CONTROLLER RED WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT END OF DASH) SBF-5 FUSE SWITCH ILLUMINATION LIGHT TAN WIRE UNLOCK UP LEFT REAR DOWN UP RIGHT FRONT UP RIGHT REAR DOWN VIO WIRE WHT WIRE

Go to component -> Power windows circuit, w/ driver"s seat off delay function (1 of 2) -> CONTROL UNIT)

control unit) wiring diagram (4 of 5)

AUTO SWITCH BLK WIRE BLK/WHT WIRE BLU WIRE BODY INTEGRATED UNIT BRN WIRE CONTROL UNIT) DOWN DRIVING UNIT FUSE 3 FUSE, RELAY BOX (F/B) GB-2 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT POWER WINDOW MOTOR LOCK LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) OFF PNK WIRE POWER WINDOW CIRCUIT BREAKER POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW RELAY POWER WINDOW SWITCH CONTROLLER RED WIRE RELAY ENERGIZED RIGHT END OF DASH) SBF-5 FUSE SWITCH ILLUMINATION LIGHT TAN WIRE UNLOCK UP DRIVER'S SIDE UP LEFT REAR UP RIGHT REAR VIO WIRE WHT WIRE

Go to component -> Power windows circuit, w/ front seats off delay function (1 of 2) -> CONTROL UNIT)

control unit) wiring diagram (5 of 5)

AUTO BLK WIRE BLU WIRE BRN WIRE CONTROL UNIT) DOWN DRIVING UNIT FRONT POWER WINDOW SUB SWITCH GB-2 GRN WIRE GRY WIRE LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH LT BLU WIRE LT GRN WIRE OFF RED WIRE RIGHT FRONT POWER WINDOW MOTOR RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH TAN WIRE VIO WIRE WHT WIRE YEL WIRE

Go to component -> Power windows circuit, w/ front seats off delay function (2 of 2) -> CONTROL UNIT)
