Subaru Forester SK facelift (2021-2024) camera switch Wiring diagrams
This page contains all the electrical diagrams for the component. camera switch, in which he is found in the car Subaru Forester SK facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
camera switch wiring diagram (1 of 3)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
CAMERA SWITCH
CAN (+)
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER 1
FRONT VIEW CAMERA (LEFT FRONT OF ENGINE COMPT)
FUSE 29
FUSE 30
FUSE 5
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2 (RIGHT KICK PANEL)
GB-4 (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IG 2 RELAY ENERGIZED
IGN
INFO
INPUT (IGN)
MAIN FUSE BOX (M/B)
MFD (UPPER CENTER OF DASH)
MFD SW+
NCA WIRE
OUTPUT (IGN)
PNK WIRE
POWER
RED WIRE
RIGHT END OF DASH)
ROLL CONNECTOR
SATELLITE SWITCH
SHIELD
STEERING HEATER SWITCH
VIDEO+
VIO WIRE
W/ FRONT VIEW MONITOR
W/ STEERING HEATER
W/O STEERING HEATER
WHT WIRE
YEL WIRE
Go to component -> Front view camera circuit -> CAMERA SWITCH
camera switch wiring diagram (2 of 3)
A/C CONTROL PANEL
AIR BAG CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CAMERA SWITCH
COMBINATION METER
COMBINATION SWITCH
DATA COMMUNICATION MODULE
DATA LINK CONNECTOR
DRIVER MONITORING SYSTEM OFF SWITCH
DRIVER MONITORING UNIT
ELECTRIC BRAKE BOOSTER CONTROL MODULE
ELECTRIC FLUID PUMP
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 5 OF 5)
FUSE, RELAY BOX (F/B)
GB-1
GB-2
GE-1
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
GRY WIRE
GT-1
GT-2
ID CODE BOX
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IMMOBILIZER CONTROL MODULE
KEYLESS ACCESS CONTROL MODULE
MEMORY HEIGHT SWITCH
MFD
NCA WIRE
OP CONNECTOR (REMOTE ENGINE START CONTROL MODULE)
PNK WIRE
POWER REAR GATE DRIVER'S SWITCH
POWER TRANSISTOR
POWER WINDOW RELAY
RIGHT END OF DASH)
SECONDARY SPEED SENSOR
SELECT LEVER
SHIFT POSITION INDICATOR
STEERING ANGLE SENSOR
TAN WIRE
TCM
TO GROUND GB-4 (DIAGRAM 3 OF 5)
TURBINE SPEED SENSOR
VDC OFF SWITCH
VIO WIRE
W/ FRONT VIEW MONITOR
W/ HIGH GRADE
W/ ID CODE BOX
W/ TELEMATICS
W/O FRONT VIEW MONITOR
WHT WIRE
X MODE SWITCH
Go to component -> Ground distribution circuit (4 of 5) -> CAMERA SWITCH
camera switch wiring diagram (3 of 3)
AVH/EPB CONTROL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAMERA SWITCH
COLOR TFT METER
DC/DC CONVERTER 1
FRONT SEAT HEATER SWITCH
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
MAIN FUSE BOX (M/B)
NCA WIRE
OP CONNECTOR (FOG LIGHT SWITCH)
PNK WIRE
POCKET LIGHT
RED WIRE
RIGHT END OF DASH)
ROLL CONNECTOR
SATELLITE SWITCH ILLUMINATION LIGHT
SBF-11 FUSE
SHIFT POSITION INDICATOR
STEERING HEATER SWITCH ILLUMINATION LIGHT
STEERING SWITCH ILLUMINATION LIGHT
TAN WIRE
VIO WIRE
W/ CONSOLE CODE
W/ FRONT VIEW MONITOR
W/O CONSOLE CODE
WHT WIRE
X MODE SWITCH
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> CAMERA SWITCH
