Subaru Forester SK facelift (2021-2024) accelerator pedal position sensor shield Wiring diagram
This page shows the only wiring diagram for the component.accelerator pedal position sensor shield, which is found in the car Subaru Forester SK facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram accelerator pedal position sensor shield (1 of 1)
A/C CONTROL PANEL
ACCELERATOR PEDAL POSITION SENSOR SHIELD
ACL
AIR BAG CONTROL MODULE
AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE
BCAN H
BCAN L
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY INTEGRATED UNIT (LEFT END OF DASH)
BRN WIRE
CAN L
CAN-H
DATA COMMUNICATION MODULE
DRIVER MONITORING UNIT
GRN WIRE
IMMOBILIZER CONTROL MODULE
INHIBITOR SWITCH
KEYLESS ENTRY CONTROL MODULE
LT GRN WIRE
MCAN-H
MCAN-L
NCA WIRE
OP CONNECTOR (REMOTE ENGINE START CONTROL MODULE)
POWER STEERING CONTROL MODULE
RED WIRE
RIGHT END OF DASH)
SHIELD
STEERING ANGLE SENSOR
STEREO CAMERA
TPMS CONTROL MODULE
TPMS, KEYLESS ENTRY CONTROL MODULE
VDC CONTROL MODULE
W/ EYESIGHT
W/O EYESIGHT
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (2 of 2) -> ACCELERATOR PEDAL POSITION SENSOR SHIELD
