Subaru Forester SK (2018-2021) up driver's side Wiring diagrams
This page contains all the electrical diagrams for the component. up driver's side, in which he is found in the car Subaru Forester SK (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram up driver's side (1 of 2)
AUTO SWITCH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY INTEGRATED UNIT
CONTROL UNIT)
DOWN
DRIVING UNIT
FUSE 3
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
LEFT FRONT POWER WINDOW MOTOR
LOCK
LT BLU WIRE
MAIN FUSE BOX (M/B)
OFF
PNK WIRE
POWER WINDOW CIRCUIT BREAKER
POWER WINDOW LOCK SWITCH
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
POWER WINDOW SWITCH CONTROLLER
RED WIRE
SBF-5 FUSE
SWITCH ILLUMINATION LIGHT
TAN WIRE
UNLOCK
UP DRIVER'S SIDE
VIO WIRE
W/O PUSH BUTTON START W/ PUSH BUTTON START
WHT WIRE
Go to component -> Power windows circuit, w/ all seats off delay function (1 of 2) -> UP DRIVER'S SIDE
Wiring diagram up driver's side (2 of 2)
AUTO SWITCH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CONTROL UNIT)
DOWN
DRIVING UNIT
FUSE 3
FUSE, RELAY BOX (F/B)
GB-2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT POWER WINDOW MOTOR
LOCK
LT BLU WIRE
LT GRN WIRE
MAIN FUSE BOX (M/B)
OFF
PNK WIRE
POWER WINDOW CIRCUIT BREAKER
POWER WINDOW LOCK SWITCH
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
POWER WINDOW SWITCH CONTROLLER
RED WIRE
RELAY ENERGIZED
SBF-5 FUSE
SWITCH ILLUMINATION LIGHT
TAN WIRE
UNLOCK
UP DRIVER'S SIDE
UP LEFT REAR
UP RIGHT REAR
VIO WIRE
W/O PUSH BUTTON START W/ PUSH BUTTON START
WHT WIRE
Go to component -> Power windows circuit, w/ front seats off delay function (1 of 2) -> UP DRIVER'S SIDE
