Subaru Forester SK (2018-2021) stop map light wiring diagram
This page shows the only wiring diagram for the component.stop map light, which is found in the car Subaru Forester SK (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop map light wiring diagram (1 of 1)
BLK WIRE
FRONT POWER WINDOW SUB SWITCH
GB-1
GB-9
HOOD SWITCH
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT FOG LIGHT
LEFT FRONT POWER WINDOW MOTOR
LEFT OUTER MIRROR ASSEMBLY
LEFT VANITY MIRROR LIGHT
MAIN FAN RELAY 2
MAIN FUSE BLOCK (M/B)
NCA WIRE
OP CONNECTOR (REAR VIEW MIRROR)
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT POWER WINDOW MOTOR
RIGHT OUTER MIRROR ASSEMBLY
RIGHT VANITY MIRROR LIGHT
ROOM LIGHT
SEAT POSITION MEMORY SWITCH
STOP MAP LIGHT
SUNROOF SWITCH (SLIDE)
SUNROOF UNIT
TELEMATICS BUTTON
TO COMBINATION SWITCH (DIAGRAM 3 OF 5)
TO GB-4 (DIAGRAM 3 OF 5)
W/ BSD/ RCTA
W/ EYESIGHT
W/ MEMORY
W/O MEMORY
W/O SRH
WARNING BOX
Go to component -> Ground distribution circuit (2 of 5) -> STOP MAP LIGHT
