Subaru Forester SK (2018-2021) shift position indicator Wiring diagrams
This page contains all the electrical diagrams for the component. shift position indicator, in which he is found in the car Subaru Forester SK (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
shift position indicator wiring diagram (1 of 4)
A/C CONTROL PANEL
AIR BAG CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
COMBINATION METER
COMBINATION SWITCH
DATA COMMUNICATION MODULE
DATA LINK CONNECTOR
DRIVER MONITORING SYSTEM OFF SWITCH
DRIVER MONITORING UNIT
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 5 OF 5)
FUSE, RELAY BOX (F/B) POWER WINDOW RELAY
GB-2
GE-1
GLOVE BOX ILLUMINATION LIGHT
GT-1
HIGH GRADE
ID CODE BOX
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IMMOBILIZER CONTROL MODULE
KEYLESS ACCESS CONTROL MODULE
MEMORY HEIGHT SWITCH
MFD
NCA WIRE
OP CONNECTOR (REMOTE ENGINE START CONTROL MODULE)
PNK WIRE
POWER REAR GATE DRIVER'S SWITCH
POWER TRANSISTOR
RIGHT END OF DASH)
SECONDARY SPEED SENSOR
SELECT LEVEL
SHIFT POSITION INDICATOR
STANDARD
STEERING ANGLE SENSOR
TAN WIRE
TCM
TO GB-4 (DIAGRAM 3 OF 5)
TOP OF TRANSMISSION)
TURBINE SPEED SENSOR
VDC OFF SWITCH
VIO WIRE
W/ TELEMATICS
WHT WIRE
X MODE SWITCH
Go to component -> Ground distribution circuit (4 of 5) -> SHIFT POSITION INDICATOR
shift position indicator wiring diagram (2 of 4)
AVH/EPB CONTROL SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
DC/DC CONVERTER 1
FRONT SEAT HEATER SWITCH
FUSE 6
FUSE, RELAY BOX (F/B)
GB-2
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
MAIN FUSE BOX (M/B)
NCA WIRE
OP CONNECTOR (FOG LIGHT SWITCH)
PNK WIRE
POCKET LIGHT
RED WIRE
RIGHT END OF DASH)
ROLL CONNECTOR
SATELLITE SWITCH
SBF-11 FUSE
SHIFT POSITION INDICATOR
STEERING HEATER SWITCH
STEERING SWITCH (COLOR TFT METER)
TAN WIRE
VIO WIRE
W/ CONSOLE CODE
W/O CONSOLE CODE
WHT WIRE
X MODE SWITCH
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> SHIFT POSITION INDICATOR
shift position indicator wiring diagram (3 of 4)
A/C CONTROL PANEL
AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY INTEGRATED UNIT
BRN WIRE
COMBINATION METER
FROM DC/DC CONVERTER 1 (DIAGRAM 2 OF 8)
FUSE 11
FUSE 16
FUSE 21
FUSE 24
FUSE 29
FUSE 30
FUSE 34
FUSE 6
GB-4
GREEN
GRN WIRE
ILLUMINATION
IMMOBILIZER
INDICATOR
KEYLESS ACCESS CONTROL MODULE
LEFT RADAR SENSOR (MASTER)
LT BLU WIRE
LT GRN WIRE
MFD
N/A
NCA WIRE
PNK WIRE
RAB CONTROL MODULE
RED WIRE
RIGHT RADAR SENSOR (MASTER)
SHIFT POSITION INDICATOR
STEREO CAMERA
TAN WIRE
TO FUSE, RELAY BOX (F/B) (DIAGRAM 6 OF 8)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 7 OF 8)
VIO WIRE
WARNING BOX
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YELLOW)
Go to component -> Power distribution circuit (4 of 8) -> SHIFT POSITION INDICATOR
shift position indicator wiring diagram (4 of 4)
ATF TEMPERATURE
AWD IND
AWD SOLENOID
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAN TRANSCEIVER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CVT/ATF TEMPERATURE IND
DC/DC -
DOWN
DUTY SOLENOID
F, R
GB-2
GB-2 (RIGHT KICK PANEL)
GB-4
GRN WIRE
GRY WIRE
IGN
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
INTERIOR LIGHT SYSTEM
LOW/MANUAL MODE SWITCH
LT BLU WIRE
LT GRN WIRE
MICROCOMPUTER
NCA WIRE
NORMAL
ORG/ WIRE
PADDLE SHIFT SWITCH (IF EQUIPPED)
PNK WIRE
PRIMARY DOWN
PRIMARY UP
RED WIRE
RIGHT END OF DASH)
ROLL CONNECTOR
SECONDARY
SELECT LEVER
SENSOR
SHIFT POSITION INDICATOR
SOLENOID
STARTING/ CHARGING SYSTEM
VDC OFF
VIO WIRE
WARNING BOX (CENTER FRONT OF ROOF)
WHT WIRE
WHT/BLK WIRE
X MODE
X MODE SWITCH (IF EQUIPPED)
YEL WIRE
YEL/GRN WIRE
Go to component -> Transmission circuit (2 of 2) -> SHIFT POSITION INDICATOR
