Subaru Forester SK (2018-2021) secondary lte rf Wiring diagrams
This page contains all the electrical diagrams for the component. secondary lte rf, in which he is found in the car Subaru Forester SK (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram secondary lte rf (1 of 2)
AIR BAG
AIR BAG CONTROL MODULE
BCAN H
BCAN L
BLK WIRE
BLU WIRE
BRN WIRE
BUTTON RS
BUTTON SOS
COMPUTER DATA LINES SYSTEM
DATA COMMUNICATION MODULE (CENTER OF DASH)
FT LH+ OUT
FT LH- IN
FT RH+ OUT
FT RH- IN
FUSE 8
FUSE, RELAY BOX (F/B)
GB-4
GPS RF
GREEN
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT W/
IGN
ILLUMINATION
INDICATOR
LED GREEN
LED RED WIRE
LEFT FRONT DOOR SPEAKER
LEFT SIDE TWEETER
LT BLU WIRE
LT GRN WIRE
MCAN-H
MCAN-L
MIC GND OUT
MIC SIG OUT
MIC-GND-(IN-)
MIC-SIG-(IN+)
MUTE
NCA WIRE
ON HOOK
ON HOOK/ VOICE
PNK WIRE
PRIMARY LTE RF
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT SIDE TWEETER
ROLL CONNECTOR
SATELLITE SWITCH
SECONDARY LTE RF
SEEK
SHIELD
SOS
SOURCE
TAN WIRE
TELEMATICS BUTTON
USB D-
USB VBUS
VBATT
VIO WIRE
VOL (-)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, w/o audio amplifier w/ telematics (2 of 2) -> SECONDARY LTE RF
