Subaru Forester SK (2018-2021) right rear load sensor 4 wiring diagram
This page shows the only wiring diagram for the component.right rear load sensor 4, which is found in the car Subaru Forester SK (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right rear load sensor 4 wiring diagram (1 of 1)
AIR BAG CONTROL MODULE
BER-
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CSR-
DSR
GRN WIRE
GRN/YEL WIRE
GRY WIRE
ICR+
LEFT FRONT LOAD SENSOR 1
LEFT REAR LOAD SENSOR 3
LT BLU WIRE
LT GRN WIRE
OCCUPANT DETECTION CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT)
PFR
PNK WIRE
PRA
PRR-
REAR FRONT LOAD SENSOR 2
RED WIRE
RIGHT ADAPTIVE BELT
RIGHT BUCKLE SWITCH
RIGHT CURTAIN AIR BAG MODULE
RIGHT LAP BELT PRETENSIONER
RIGHT REAR LOAD SENSOR 4
RIGHT REAR SEAT BELT PRETENSIONER
RIGHT SEAT BELT PRETENSIONER
RIGHT SEAT POSITION SENSOR
RIGHT SIDE AIR BAG MODULE
RIGHT SIDE IMPACT SENSOR (CENTER PILLAR)
RIGHT SIDE IMPACT SENSOR (FRONT DOOR)
RIGHT SIDE IMPACT SENSOR (REAR WHEEL HOUSE)
RSP+
SFR-
SSR- PNK SSR+ WIRE
TAN WIRE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> RIGHT REAR LOAD SENSOR 4
