Subaru Forester SK (2018-2021) keyless access cm Wiring diagram
This page shows the only wiring diagram for the component.keyless access cm, which is found in the car Subaru Forester SK (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram keyless access cm (1 of 1)
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CAN H B
CAN L
CAN L (B)
COMPUTER DATA LINES SYSTEM
D LK (D UL) PNK FUEL LID WIRE
D SW (RG)
FUEL LID LOCK ACTUATOR
FUSE HOLDER
GB-11
GB-4
GRN WIRE
GRY WIRE
KEYLESS ACCESS CM
LEFT FRONT DOOR LOCK LOCK ACTUATOR
LIN 1
LT BLU WIRE
LT GRN WIRE
MEMORY HEIGHT SWITCH
NCA WIRE
OPN SW (RG)
PNK WIRE
POWER REAR GATE DRIVER SWITCH
POWER REAR GATE LOCK BUTTON
REAR GATE OPENER BUTTON
REAR LOCK BUTTON, REAR GATE OPENER BUTTON
RED WIRE
SUNROOF UNIT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power door closer circuit (2 of 2) -> KEYLESS ACCESS CM
