Subaru Forester SJ facelift (2015-2016) right remote control back rest actuator Wiring diagrams

& RECEIVER 2.0L TURBO 2.5L AUDIO AMPLIFIER BLK WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE FRONT WHEEL SPEED SENSOR FUEL PUMP ASSEMBLY FUEL PUMP CONTROL UNIT GAP- GB-10 GB-11 GB-12 GB-9 HIGH MOUNTED STOP LIGHT INHIBITOR SWITCH KEYLESS ENTRY CONTROL MODULE LEFT CONDENSER LEFT FRONT DOOR SWITCH LEFT LICENSE PLATE LIGHT LEFT POWER SEAT LEFT POWER SEAT SWITCH LEFT REAR COMBINATION LIGHT LEFT REAR DOOR SWITCH LEFT REMOTE CONTROL BACK REST ACTUATOR LEFT SEAT BELT SWITCH LEFT SEAT HEATER LEFT SEAT HEATER SWITCH LUMBAR SWITCH NCA WIRE PNK WIRE POWER REAR GATE AUTO CLOSER POWER REAR GATE BUZZER POWER REAR GATE CONTROL MODULE POWER REAR GATE DRIVE UNIT POWER STEERING CONTROL MODULE PRIMARY SPEED SENSOR REAR ACCESSORY POWER SUPPLY SOCKET (CARGO ROOM) REAR ACCESSORY POWER SUPPLY SOCKET (CONSOLE) REAR DEFOGGER REAR GATE LOCK ACTUATOR, LATCH SWITCH REAR GATE OPENER BUTTON REAR LOCK BUTTON, REAR GATE OPENER BUTTON, REAR KEYLESS ACCESS EXTERIOR ANTENNA REAR WIPER MOTOR RIGHT CONDENSER RIGHT FRONT DOOR SWITCH RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT RIGHT REAR DOOR SWITCH RIGHT REMOTE CONTROL BACK REST ACTUATOR RIGHT SEAT HEATER RIGHT SEAT HEATER SWITCH SECONDARY SPEED SENSOR TCM TPMS CONTROL MODULE TPMS, KEYLESS ENTRY CONTROL MODULE TRAILER CONNECTOR TURBINE SPEED SENSOR VDC CONTROL MODULE W/O FUEL PUMP CONTROL UNIT W/O PUSH BUTTON START W/ PUSH BUTTON START WHT WIRE

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE FUSE 3 FUSE, RELAY BOX (F/B) GB-11 GB-9 GRN WIRE HOT AT ALL TIMES LEFT CONDENSER LEFT REMOTE CONTROL BACK REST ACTUATOR LEFT REMOTE CONTROL BACK REST SWITCH POWER DISTRIBUTION SYSTEM RIGHT CONDENSER RIGHT REMOTE CONTROL BACK REST ACTUATOR RIGHT REMOTE CONTROL BACK REST SWITCH WHT WIRE WHT/GRN WIRE YEL WIRE
