Subaru Forester SJ facelift 2 (2016-2018) mfd switch Wiring diagrams
This page contains all the electrical diagrams for the component. mfd switch, in which he is found in the car Subaru Forester SJ facelift 2 (2016-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mfd switch (1 of 3)
A/C CONTROL PANEL
AUTO
BLK WIRE
BLK/WHT WIRE
BSD/RCTA OFF SWITCH
COMBINATION SWITCH
GB-3
LANE DEPARTURE WARNING OFF IND
LIGHTING
LT GRN WIRE
MANUAL A/C AUTOMATIC A/C
MEMORY HEIGHT SWITCH
MFD SWITCH
OFF
OPTION CONNECTOR (FOG LIGHT SWITCH)
OVERHEAD CONSOLE (SHOWER LIGHT)
POCKET LIGHT
PRE-COLLISION BRAKE OFF IND
RED WIRE
SRH OFF SWITCH
STEREO CAMERA COVER (SHOWER LIGHT)
SWITCH
VIO WIRE
W/ EYESIGHT
W/ EYESIGHT W/O EYESIGHT
W/O EYESIGHT
WHT WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> MFD SWITCH
Wiring diagram mfd switch (2 of 3)
A/C CONTROL PANEL
ACCESSORY RELAY
AUDIO
AUTOMATIC A/C
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BSD/RCTA OFF SWITCH
DAYTIME RUNNING LIGHT RELAY
FROM AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE (DIAGRAM 3 OF 5)
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 2 OF 5)
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 3 OF 5)
FROM FUSE, RELAY BOX (F/B) (DIAGRAM 4 OF 5)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 5)
FROM POWER WINDOW CIRCUIT BREAKER (DIAGRAM 4 OF 5)
FROM REMOTE ENGINE START CONTROL MODULE (DIAGRAM 4 OF 5)
FUSE HOLDER
GB-5
GB-7
GRN WIRE
GRN/RED WIRE
GRY WIRE
HAZARD SWITCH
IG RELAY 1
IG RELAY 2
ILLUMINATION CONTROL SWITCH
KEYLESS ACCESS CONTROL MODULE
LEFT FRONT COMBINATION LIGHT (SRH ACTUATOR)
LEFT POWER SEAT (W/ MEMORY)
LEFT SEAT HEATER SWITCH
LUMBAR SWITCH
MANUAL A/C
MEMORY HEIGHT SWITCH
MFD SWITCH
NAVIGATION UNIT
NCA WIRE
OP CONNECTOR (FOG LIGHT SWITCH)
PNK WIRE
POCKET LIGHT
POWER SEAT CONTROL MODULE
PUSH BUTTON IGNITION SWITCH
REAR SEAT HEATER SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT COMBINATION LIGHT (SRH ACTUATOR)
RIGHT SEAT HEATER SWITCH
ROLL CONNECTOR
STARTER RELAY
STEERING HEATER SWITCH
TAN WIRE
TO FUSE, RELAY BOX (F/B) (DIAGRAM 3 OF 5)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 4 OF 5)
VDC OFF SWITCH
VDC OFF, POWER REAR GATE DRIVER'S SWITCH
VIO WIRE
W/ AMPLIFIER
W/ LED
W/ NAVIGATION
W/O AMPLIFIER
W/O NAVIGATION
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> MFD SWITCH
Wiring diagram mfd switch (3 of 3)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSTANT VOLTAGE CIRCUIT
DOWN SWITCH
DRIVE CIRCUIT
ENTER SWITCH
FUSE 4
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B)
GB-7
GB-9 (UNDER DRIVER'S SEAT)
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ IG 2 RELAY ENERGIZED
ILLUMINATION
LEFT CORNER SONAR SENSOR
LEFT INNER SONAR SENSOR
MFD (UPPER CENTER OF DASH)
MFD SWITCH
MICRO COMPUTER
MICROCOMPUTER
NCA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY CIRCUIT
RAB CONTROL MODULE
RED WIRE
RIGHT CORNER SONAR SENSOR
RIGHT INNER SONAR SENSOR
SPEAKER
STEREO CAMERA
TAN WIRE
UP SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Reverse automatic braking system circuit -> MFD SWITCH
