Subaru Forester SJ facelift 2 (2016-2018) left side turn light ind Wiring diagram
This page shows the only wiring diagram for the component.left side turn light ind, which is found in the car Subaru Forester SJ facelift 2 (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side turn light ind (1 of 1)
& RECEIVER
2.0L TURBO
2.5L
AMBIENT SENSOR
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BUZZER
CIRCUIT
CLOCK DISPLAY SWITCH
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR IND
DOOR LOCKS, ANTI-THEFT SYSTEMS
DRIVE
DRIVE CIRCUIT
DRIVE CIRCUIT (DIMMER)
ECO GAUGE
EEPROM
ENGINE CONTROLS SYSTEM
FRONT FOG LIGHT IND
FUEL LEVEL IND
FUEL PUMP ASSEMBLY (FUEL LEVEL SENSOR)
FUEL SUB LEVEL SENSOR
FUSE 15
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B)
GB-4
GB-7
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
LCD
LCD ILLUM LIGHT IND
LEFT SIDE TURN LIGHT IND
LIGHTING IND (IF EQUIPPED)
LT BLU WIRE
LT GRN WIRE
MICROCOMPUTER
NEEDLE ILLUM LIGHT IND
OIL PRESSURE SWITCH
PARKING BRAKE/BRAKE FLUID LEVEL IND
PARKING BRAKE/BRAKE FLUID LEVEL/ BRAKE VACUUM PUMP IND
PLATE ILLUM LIGHT IND
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT SIDE TURN LIGHT IND
SEAT BELT KEY WARNING HEADLIGHT ON WARNING CUSTOMIZED KEYLESS ACCESS SI-DRIVE
SECURITY IND
SPEEDOMETER
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAN WIRE
TO ABS IND (DIAGRAM 3 OF 3)
TRANSCEIVER/
TRIP SWITCH
VIO WIRE
WARNING SYSTEMS
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLK WIRE
Go to component -> Instrument cluster circuit (1 of 3) -> LEFT SIDE TURN LIGHT IND
