Front wiper/washer circuit for Subaru Forester SJ (2012-2015)
Front wiper/washer circuit
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BODY INTEGRATED UNIT (LEFT SIDE OF DASH)
BRN/WHT WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
FRONT WASHER MOTOR (WASHER FLUID RESERVOIR)
FRONT WASHER SWITCH ON
FRONT WIPER MOTOR (LEFT SIDE OF FIREWALL)
FRONT WIPER SWITCH
FUSE
GB-6 (CENTER OF DASH)
GRN/YEL WIRE
HI OFF HI OFF INT LO LO LO INT
HOT IN ACC OR ON DRIVER SIDE FUSE, RELAY BLOCK (LEFT SIDE OF DASH)
HOT IN ACC OR ON FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
INTERMITTENT VOLUME
MIST
MIST SWITCH
NCA WIRE
OFF
OFF HI HI OFF LO INT
OFF INT
PC BOARD
RED WIRE
RED/BLU WIRE
WIPER MOTOR
YEL/BLK WIRE
