Remote control back rest circuit for Subaru Forester SJ (2012-2015)
Remote control back rest circuit
BLK WIRE
BLK/ YEL WIRE
BLU WIRE
BLU/RED WIRE
FUSE
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-8 (RIGHT FRONT FLOOR PAN)
HOT AT ALL TIMES
LEFT REMOTE CONTROL BACK REST SWITCH
LEFT REMOTE CONTROLLED BACK REST ACTUATOR (LEFT SIDE OF LEFT REAR SEAT)
PNK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RIGHT REMOTE CONTROL BACK REST SWITCH
RIGHT REMOTE CONTROLLED BACK REST ACTUATOR (RIGHT SIDE OF RIGHT REAR SEAT)
YEL WIRE
