Power mirror circuit, with retractable outer mirror for Subaru Forester SJ (2012-2015)
Power mirror circuit, with retractable outer mirror
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
DN UP
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-11 (CENTER OF DASH)
GRY WIRE
GRY/RED WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
JOINT GROUND
LEFT OUTER MIRROR ASSEMBLY
MIRROR HEATER
MIRROR HEATER RETRACTABLE MOTOR
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
REMOTE CONTROL MIRROR SWITCH
REMOTE CONTROL SWITCH
RETRACTION SWITCH
RH DN LH UP
RH LH
RIGHT OUTER MIRROR ASSEMBLY
TURN LIGHT
TURN RETRACTABLE LIGHT MIRROR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
