Backup lamps circuit for Subaru Forester SJ (2012-2015)
Backup lamps circuit
A/T M/T
AUDIO
BACKUP LIGHT
BACKUP LIGHT LEFT REAR COMBINATION LIGHT
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (LEFT SIDE OF DASH)
BRN WIRE
BRN/YEL WIRE
FUSE 18
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-7 (BEHIND RIGHT REAR QUARTERPANEL)
GB-9 (BEHIND LEFT REAR QUARTERPANEL)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
MULTI JOINT CONNECTOR
NAVIGATION UNIT
NCA WIRE
POWER DISTRIBUTION SYSTEM
REARVIEW MIRROR)
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
TRAILER CONNECTOR (LEFT REAR OF LUGGAGE COMPT)
W/ DVD NAVIGATION W/ SD CARD NAVIGATION
W/ NAVIGATION
W/0 NAVIGATION
YEL WIRE
