Wiper deicer circuit for Subaru Forester SJ (2012-2015)

Wiper deicer circuit

Get access

16 1 9 27 PNK COMPUTER DATA LINES SYSTEM WIRE 7 6 WIPER DEICER, REAR DEFOGGER SWITCH A/C CONTROL PANEL AUTOMATIC A/C BLK WIRE BLK/ YEL WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BODY INTEGRATED UNIT (LEFT SIDE OF DASH) BRN/BLU WIRE DRIVER SIDE WIPER FUSE DEICER, RELAY RELAY BLOCK (LEFT SIDE OF DASH) FUSE 10 FUSE 22 FUSE 4 FUSE 9 (LEFT KICK PANEL) FUSE, RELAY BOX (F/B) GB-3 (RIGHT KICK PANEL) GRN/ORG WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON J/C MAIN SBF FUSE MANUAL A/C MIRROR HEATER, REAR DEFOGGER CIRCUIT REAR DEFOGGER RELAY RED/BLU WIRE RED/YEL WIRE RELAY ENERGIZED VIO/GRN WIRE WIPER DEICER (BASE OF RIGHT "A" PILLAR)
