Subaru Forester SJ (2012-2015) multi joint connector Wiring diagrams
This page contains all the electrical diagrams for the component. multi joint connector, in which he is found in the car Subaru Forester SJ (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
multi joint connector wiring diagram (1 of 5)
A/T M/T
AUDIO
BACKUP LIGHT
BACKUP LIGHT LEFT REAR COMBINATION LIGHT
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (LEFT SIDE OF DASH)
BRN WIRE
BRN/YEL WIRE
FUSE 18
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-7 (BEHIND RIGHT REAR QUARTERPANEL)
GB-9 (BEHIND LEFT REAR QUARTERPANEL)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
MULTI JOINT CONNECTOR
NAVIGATION UNIT
NCA WIRE
POWER DISTRIBUTION SYSTEM
REARVIEW MIRROR)
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
TRAILER CONNECTOR (LEFT REAR OF LUGGAGE COMPT)
W/ DVD NAVIGATION W/ SD CARD NAVIGATION
W/ NAVIGATION
W/0 NAVIGATION
YEL WIRE
Go to component -> Backup lamps circuit -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (2 of 5)
BACKUP LIGHT CIRCUIT
BACKUP LIGHT TURN
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BRN WIRE
CLEAR- ANCE LIGHT
COMBINATION METER
COMBINATION SWITCH (LEFT SIDE OF DASH)
FUSE
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-10 (CENTER OF DASH)
GB-11 (CENTER OF DASH)
GB-6 (CENTER OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
GB-9 (BEHIND LEFT REAR QUARTERPANEL)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
LEFT OUTER MIRROR ASSEMBLY
LEFT TURN
LICENSE PLATE LIGHT
LT GRN WIRE
LT GRN/RED WIRE
LT PNK WIRE
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) FUSE 14
MULTI JOINT CONNECTOR
NCA WIRE
OFF TURN SIGNAL SWITCH
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT OUTER MIRROR ASSEMBLY
RIGHT REAR COMBINATION LIGHT
RIGHT TURN
SBF-2 FUSE
STOP LIGHT
TRAILER CONNECTOR (LEFT REAR OF LUGGAGE COMPARTMENT)
TURN SIGNAL, HAZARD UNIT (LEFT SIDE OF DASH)
VIO WIRE
W/ LUMINESCENT METER W/ HEATED MIRRORS W/O HEATED MIRRORS
W/ MIRROR W/O MIRROR TURN TURN
W/ NORMAL METER
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (3 of 5)
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
CAN TRANSCEIVER, RECEIVER
COMBINATION METER
COMBINATION SWITCH (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DAYTIME RUNNING LIGHT RELAY
DAYTIME RUNNING LIGHT RESISTOR (RIGHT SIDE OF ENGINE COMPT)
DIMMER, PASSING SWITCH
FRONT FOG LIGHT
FRONT FOG LIGHT RELAY (DRIVER SIDE FUSE, RELAY BLOCK)
FRONT FOG LIGHT SWITCH
FUSE 29
FUSE 7
FUSE, RELAY BOX (F/B) (LEFT KICK
GB-10 (CENTER OF DASH)
GB-5 (LEFT SIDE OF DASH)
GRN WIRE
GRN/WHT WIRE
HI-BEAM IND
HOT AT ALL TIMES
IND
LIGHT DRIVE CIRCUIT
LIGHTING SWITCH
LO HI
MICRO COMPUTER
MULTI JOINT CONNECTOR
NCA WIRE
OFF
PANEL)
PASS
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLU WIRE
RELAY HOLDER
THROUGH JOINT CONNECTOR
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps circuit (1 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (4 of 5)
28 1 9 PNK COMPUTER DATA LINES SYSTEM WIRE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (LEFT SIDE OF DASH)
BRN WIRE
BRN/RED WIRE
FUSE
FUSE 14
FUSE 15
FUSE 6
FUSE 7
GB-1 (RIGHT FRONT OF ENGINE COMPT)
GB-10 (CENTER OF DASH)
GB-2 (LEFT FRONT OF ENGINE COMPT)
GB-5 (LEFT SIDE OF DASH)
GRN/WHT (OR WHT) WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HIGH HEADLIGHT RELAY
HOT AT ALL TIMES
J/C
KEY WARNING SWITCH (LEFT SIDE OF DASH)
LEFT FRONT COMBINATION LIGHT
LEFT FRONT FOG LIGHT
LOW HEADLIGHT RELAY
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MULTI JOINT CONNECTOR
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER)
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY HOLDER FUSE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT FOG LIGHT
THROUGH JOINT CONNECTOR
VIO/RED WIRE
VIO/YEL WIRE
WHT GRN/ WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps circuit (2 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (5 of 5)
A/C CONTROL PANEL
AUTOMATIC A/C
BLK/ WHT WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
CIRCUIT DIMMER DRIVE
CIRCUIT DRIVE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CUP HOLDER
DIMMER CIRCUIT
DRIVE
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-10 (CENTER OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR NEEDLE ILLUMINATION LIGHT
JOINT
JOINT CONNECTOR
LCD ILLUMINATION LIGHT IND
LIGHTING INDICATOR
MANUAL A/C
MICRO COMPUTER
MULTI JOINT CONNECTOR
PLATE ILLUMINATION LIGHT
PNK WIRE
POCKET LIGHT
POWER
SEAT HEATER SWITCH
SUPPLY CIRCUIT/
VIO WIRE
W/ DVD NAVIGATION
W/O DVD NAVIGATION
W/O NAVIGATION
W/O NAVIGATION AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION)
WHT/ BLK WIRE
WHT/BLU WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> MULTI JOINT CONNECTOR
