Subaru Forester SJ (2012-2015) joint ground connector Wiring diagram
This page shows the only wiring diagram for the component.joint ground connector, which is found in the car Subaru Forester SJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram joint ground connector (1 of 1)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
DN MIRROR HEATER UP
DN RH LH UP
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-11 (CENTER OF DASH)
GRY WIRE
GRY/RED WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
JOINT GROUND CONNECTOR
LEFT OUTER MIRROR ASSEMBLY
MIRROR HEATER
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
REMOTE CONTROL MIRROR SWITCH
REMOTE CONTROL SWITCH
RIGHT OUTER MIRROR ASSEMBLY
TURN LIGHT TURN LIGHT RH LH
W/ HEATED MIRRORS W/O HEATED MIRRORS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power mirror circuit, without retractable outer mirror -> JOINT GROUND CONNECTOR
