Subaru Forester SH facelift (2010-2013) vdc warning light/ vdc off light ind wiring diagram

33 1 9 6 32 20 19 PNK WIRE ABS WARNING LIGHT IND AIR BAG IND PASSENGER'S AIR BAG OFF IND PASSENGER'S AIR BAG ON IND PASSENGER'S AIR BAG WARNING LIGHT IND ATF TEMPERATURE WARNING LIGHT IND (A/T) AWD/HILL START ASSIST WARNING LIGHT IND BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BODY INTEGRATED UNIT (BEHIND CENTER OF DASH) BRN/GRN WIRE CLOCK COMBINATION METER COMPUTER DATA LINES SYSTEM CONSTANT VOLTAGE CIRCUIT CRUISE CONTROL IND CRUISE SET IND DRIVE CIRCUIT ENGINE COOLANT TEMP IND ENGINE COOLANT TEMP WARNING LIGHT IND FROM PARKING BRAKE/ BRAKE FLUID LEVEL WARNING LIGHT IND (DIAGRAM 1 OF 2) FUEL PUMP ASSEMBLY (FUEL LEVEL SENSOR) FUEL SUB LEVEL SENSOR (FUEL TANK) GB-10 (CENTER OF DASH) GB-7 (BEHIND RIGHT REAR QUARTERPANEL) GB-8 (RIGHT FRONT FLOOR PAN) GB-9 (BEHIND LEFT REAR QUARTERPANEL) GRY WIRE LEFT FRONT DOOR SWITCH (LEFT "B" PILLAR) LEFT REAR DOOR SWITCH (LEFT "C" PILLAR) LEFT TURN SIGNAL LIGHT IND MICRO COMPUTER ORG/GRN WIRE ORG/WHT WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER) PASSENGER'S SEAT BELT WARNING LIGHT IND REAR GATE LATCH SWITCH (CENTER OF REAR GATE) RED/WHT WIRE REMOTE ENGINE START CONTROL MODULE (IF EQUIPPED) (LEFT SIDE OF DASH) REVERSE CIRCUIT RIGHT FRONT DOOR SWITCH (RIGHT "B" PILLAR) RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR) RIGHT TURN SIGNAL LIGHT IND SEAT BELT WARNING LIGHT IND SPORT IND (A/T) SUPPLEMENTAL RESTRAINTS SYSTEM TIRE INFLATION PRESSURE WARNING LIGHT IND VDC OPERATOR LIGHT IND VDC WARNING LIGHT/ VDC OFF LIGHT IND VFD (AMBIENT, AVERAGE FUEL ECONOMY, CLOCK DISPLAY) VIO/RED WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE YEL/WHT WIRE
