Headlamps & fog lamps circuit for Subaru Forester SH (2007-2011)

BLK WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE CAN TRANSCEIVER, RECEIVER COMBINATION METER COMBINATION SWITCH COMPUTER DATA LINES SYSTEM DAYTIME RUNNING LIGHT RELAY DAYTIME RUNNING LIGHT RESISTOR (NEAR RIGHT HEADLIGHT) DIMMER, PASSING SWITCH ENGINE COMPT) FOG LIGHT SWITCH FRONT FOG IND FRONT FOG LIGHT RELAY (BEHIND LEFT SIDE OF DASH, IN RELAY BLOCK) FUSE 29 FUSE 7 FUSE, RELAY BOX (F/B) (BEHIND LEFT GB-10 (HO TURBO: UNDER CENTER OF DASH) GB-5 (BEHIND CENTER OF DASH) GRN WIRE GRN/WHT WIRE HI PASS HI-BEAM IND HOT AT ALL TIMES JOINT GROUND LIGHT LIGHT DRIVE CIRCUIT LIGHTING SWITCH MICRO COMPUTER MULTI JOINT CONNECTOR NCA WIRE PARK OFF PASS HEAD PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RED/BLU WIRE RELAY HOLDER SIDE OF DASH) THROUGH JOINT CONNECTOR VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE

28 1 9 PNK WIRE BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BODY INTEGRATED UNIT (BEHIND LEFT SIDE OF DASH) BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPT) FUSE FUSE 14 FUSE 15 FUSE 6 FUSE 7 GB-1 (NEAR RIGHT HEADLIGHT) GB-2 (NEAR THE LEFT HEADLIGHT) GB-5 (BEHIND CENTER OF DASH) GRN/WHT WIRE GRN/YEL WIRE HIGH HEADLIGHT RELAY HOT AT ALL TIMES J/C KEY WARNING SWITCH LEFT FRONT COMBINATION LIGHT LEFT FRONT FOG LIGHT LOW HEADLIGHT RELAY LT GRN/RED WIRE MAIN FUSE BOX (M/B) (LEFT REAR OF ENGINE COMPT) MULTI JOINT CONNECTOR POWER DISTRIBUTION SYSTEM RED WIRE RELAY HOLDER FUSE RIGHT FRONT COMBINATION LIGHT RIGHT FRONT FOG LIGHT THROUGH JOINT CONNECTOR VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE
