Subaru Forester SH (2007-2011) vdc operation light ind Wiring diagram

BLK WIRE BLK/YEL WIRE BLU WIRE BODY INTEGRATED UNIT (BEHIND CENTER OF DASH) BRAKE FLUID LEVEL SWITCH (BRAKE FLUID RESERVOIR) BRN/RED WIRE BRN/WHT WIRE CAN I/F TRANSCEIVER, RECEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR DRIVER CIRCUIT FUSE 1 FUSE 33 FUSE 5 GB-11 (CENTER OF DASH) GB-3 (RIGHT SIDE OF DASH) GB-4 (CENTER OF DASH) GB-5 (LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE GV (RIGHT SIDE OF ENGINE COMPT) HILL START ASSIST WARNING LIGHT IND HOT AT ALL TIMES HOT AT ALL TIMES FUSE, RELAY BOX FUSE 8 (F/B) (BEHIND LEFT SIDE OF DASH) HOT IN ON OR START LEFT FRONT ABS WHEEL SPEED SENSOR (2.5L: LEFT FRONT HUB ASSEMBLY) LEFT FUSE, RELAY BOX (F/B) LEFT REAR ABS WHEEL SPEED SENSOR LIGHT/ VDC OFF LIGHT IND LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) MICRO COMPUTER MOTOR RELAY MULTI J/C NCA WIRE ORG/ WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER) PARKING BRAKE/BRAKE FLUID LEVEL WARNING LIGHT IND PNK 1 9 COMPUTER DATA LINES SYSTEM WIRE PNK WIRE PNK/GRN WIRE PRIMARY CUT RR OUT RR IN RL OUT RL IN FR OUT FR IN FL OUT FL IN PRIMARY SUCTION PUMP MOTOR RED WIRE RED/YEL WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR (2.5L TURBO: RIGHT FRONT HUB ASSEMBLY) RIGHT REAR ABS WHEEL SPEED SENSOR SBF-1 FUSE SECONDARY CUT SOLENOID VALVE SECONDARY SUCTION STEERING ANGLE SENSOR (IN STEERING COLUMN) VALVE RELAY VDC CONTROL MODULE (RIGHT SIDE OF DASH) VDC OFF SWITCH VDC OPERATION LIGHT IND VDC WARNING VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YAW RATE, LATERAL G SENSOR (UNDER CENTER FLOOR CONSOLE)
