Subaru Forester SH (2007-2011) rear gate lock actuator, latch switch Wiring diagrams
This page contains all the electrical diagrams for the component. rear gate lock actuator, latch switch, in which he is found in the car Subaru Forester SH (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear gate lock actuator, latch switch (1 of 2)
2.5L
2.5L TURBO 2.5L
AT SELECT LEVER
AUTO HEADLIGHT
BEAM LEVELER CONTROL MODULE (IF EQUIPPED)
BLK WIRE
BLK/BLU WIRE
BLK/YEL (OR BLK) WIRE
BLK/YEL WIRE
BODY INTEGRATED UNIT
BRAKE FLUID LEVEL SWITCH
COMPASS MIRROR
CONTROL UNIT)
CUP HOLDER
FRONT WIPER MOTOR
FUEL PUMP ASSEMBLY
FUEL PUMP CONDENSER
FUEL PUMP CONTROL UNIT (2.5L TURBO)
FUEL PUMP RELAY (2.5L TURBO)
FUSE, RELAY BOX (F/B)
GB-1 (RIGHT FRONT OF ENGINE COMPT)
GB-2 (LEFT FRONT WHEELWELL)
GB-3 (RIGHT SIDE OF DASH) COMBINATION SWITCH
GB-5 (LEFT SIDE OF DASH)
GB-6 (CENTER OF DASH)
GB-7 (RIGHT REAR OF VEHICLE CHASSIS)
GB-8 (RIGHT FRONT FLOOR PAN)
GB-9 (LEFT REAR OF VEHICLE CHASSIS)
GRN/RED (OR BLK) WIRE
GRN/RED WIRE
HIGH MOUNTED STOP LIGHT
HOOD SWITCH WIPER DEICER
IMPACT SENSOR
INHIBITOR SWITCH
KEY LOCK SOLENOID, KEY WARNING SWITCH (A/T)
KEYLESS BUZZER
KEYLESS ENTRY CONTROL MODULE
LEFT FRONT COMBINATION LIGHT
LEFT FRONT DOOR SWITCH
LEFT FRONT FOG LIGHT
LEFT REAR COMBI- NATION LIGHT LEFT POWER SEAT
LEFT REAR DOOR SWITCH
LEFT SEAT BELT SWITCH
LICENSE PLATE LIGHT
LUGGAGE ROOM LIGHT
MAIN FAN MOTOR
MAIN FAN RELAY 2
POWER TRANSISTOR (AUTO A/C)
POWER WINDOW RELAY
PRESSURE SWITCH
REAR ACCE- SSORY POWER SUPPLY SOCKET (CONSOLE) REAR ACCE- SSORY POWER
REAR DEFOGGER
REAR GATE LOCK ACTUATOR, LATCH SWITCH
REAR GATE RELEASE SWITCH
REAR WIPER MOTOR
REMOTE ENGINE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT DOOR SWITCH
RIGHT FRONT FOG LIGHT
RIGHT REAR DOOR SWITCH RIGHT REAR COMBI- NATION LIGHT
ROOM LIGHT
SEAT HEATER RELAY
SEAT HEATER SWITCH
SPOT MAP LIGHT
STEERING ANGLE SENSOR
SUPPLY SOCKET (LUGGAGE ROOM)
TPMS CONTROL MODULE
TRAILER CONNECTOR
TURN SIGNAL, HAZARD MODULE
VDC CONTROL MODULE
VDC OFF SWITCH
W/ O SUNROOF W/ SUNROOF
YAW RATE DELIVERY, LATERAL (TEST) G SENSOR MODE CONNECTOR
YEL/RED WIRE
Go to component -> Ground distribution circuit (1 of 3) -> REAR GATE LOCK ACTUATOR, LATCH SWITCH
Wiring diagram rear gate lock actuator, latch switch (2 of 2)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (BEHIND CENTER OF DASH)
BRN WIRE
BRN/WHT WIRE
ENGINE CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
FUSE 14
FUSE 8
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-3 (RIGHT SIDE OF DASH)
GB-4 (CENTER OF DASH)
GB-7 (RIGHT REAR OF VEHICLE CHASSIS)
GB-8 (RIGHT FRONT FLOOR PAN)
GB-9 (LEFT REAR OF VEHICLE CHASSIS)
GRN/ORG WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOOD SWITCH (RIGHT FRONT OF ENGINE COMPT)
HORNS SYSTEM
HOT AT ALL TIMES
KEY WARNING SWITCH (LEFT SIDE OF DASH)
LEFT FRONT DOOR LOCK ACTUATOR (REAR OF LEFT FRONT DOOR)
LEFT FRONT DOOR SWITCH
LEFT FUSE, RELAY BOX (F/B)
LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR)
LEFT REAR DOOR SWITCH (REAR OF LEFT REAR DOOR)
LOCK
LT GRN WIRE
LT GRN/YEL WIRE
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MULTI J/C
NCA WIRE
ORG/WHT WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
REAR GATE LOCK ACTUATOR, LATCH SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
REMOTE ENGINE START CONTROL MODULE (LEFT SIDE OF DASH)
RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF RIGHT FRONT DOOR)
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR)
RIGHT REAR DOOR SWITCH
STOP, BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
UNLOCK
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Remote starting circuit -> REAR GATE LOCK ACTUATOR, LATCH SWITCH
