Subaru Forester SH (2007-2011) multi joint connector Wiring diagrams
This page contains all the electrical diagrams for the component. multi joint connector, in which he is found in the car Subaru Forester SH (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
multi joint connector wiring diagram (1 of 9)
A/C CONTROL PANEL
AIR MIX DOOR ACTUATOR (RIGHT SIDE OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND LOWER RIGHT SIDE OF DASH)
BLOWER MOTOR RELAY (RIGHT SIDE OF DASH)
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (TOP (BEHIND RIGHT SIDE CENTER OF DASH) OF DASH)
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
FUSE 22
FUSE 26
FUSE 28 FUSE 7
FUSE 31
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-10 (CENTER OF DASH)
GB-3 (RIGHT SIDE OF DASH)
GB-5 (LEFT PRESSURE SWITCH SIDE OF (LEFT REAR OF DASH) ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR ACC
HOT IN ON OR START
INTAKE DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH)
JOINT CONNECTOR
LT BLU WIRE
LT GRN WIRE
LT GRN/WHT WIRE
MODE DOOR ACTUATOR
MULTI JOINT CONNECTOR
ORG/GRN WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
POWER TRANSISTOR (RIGHT SIDE OF DASH)
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
SUN LOAD SENSOR
VIO WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (2 of 9)
A/T M/T
BACKUP LIGHT
BACKUP LIGHT LEFT REAR COMBINATION LIGHT
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (M/T) (BEHIND CENTER OF DASH)
BRN WIRE
BRN/YEL WIRE
COMPASS MIRROR
FUSE 18
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
MULTI JOINT CONNECTOR
NCA WIRE
POWER DISTRIBUTION SYSTEM
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
TRAILER CONNECTOR
YEL WIRE
Go to component -> Backup lamps circuit -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (3 of 9)
BACKUP LIGHT CIRCUIT
BACKUP LIGHT TURN
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CLEAR- ANCE LIGHT
COMBINATION METER
FUSE
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-10 (CENTER OF DASH)
GB-6 (CENTER OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
GB-9 (LEFT REAR OF VEHICLE CHASSIS)
GRN WIRE
GRN/BLK WIRE
HAZARD SWITCH
HOT AT ALL TIMES
JOINT GROUND
JOINT GROUND CONNECTOR
LEFT TURN
LICENSE PLATE LIGHT
LT GRN WIRE
LT PNK WIRE
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) FUSE 14
MULTI JOINT CONNECTOR
NCA WIRE
OF DASH)
OFF
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT REAR COMBINATION LAMP
RIGHT TURN
SBF-2 FUSE
STOP LIGHT
TRAILER CONNECTOR
TURN SIGNAL SWITCH
TURN SIGNAL, HAZARD UNIT (LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (4 of 9)
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
CAN TRANSCEIVER, RECEIVER
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DAYTIME RUNNING LIGHT RELAY
DAYTIME RUNNING LIGHT RESISTOR (NEAR RIGHT HEADLIGHT)
DIMMER, PASSING SWITCH
ENGINE COMPT)
FOG LIGHT SWITCH
FRONT FOG IND
FRONT FOG LIGHT RELAY (BEHIND LEFT SIDE OF DASH, IN RELAY BLOCK)
FUSE 29
FUSE 7
FUSE, RELAY BOX (F/B) (BEHIND LEFT
GB-10 (HO TURBO: UNDER CENTER OF DASH)
GB-5 (BEHIND CENTER OF DASH)
GRN WIRE
GRN/WHT WIRE
HI PASS
HI-BEAM IND
HOT AT ALL TIMES
JOINT GROUND
LIGHT
LIGHT DRIVE CIRCUIT
LIGHTING SWITCH
MICRO COMPUTER
MULTI JOINT CONNECTOR
NCA WIRE
PARK OFF
PASS HEAD
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLU WIRE
RELAY HOLDER
SIDE OF DASH)
THROUGH JOINT CONNECTOR
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps & fog lamps circuit (1 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (5 of 9)
28 1 9 PNK WIRE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FUSE
FUSE 14
FUSE 15
FUSE 6
FUSE 7
GB-1 (NEAR RIGHT HEADLIGHT)
GB-2 (NEAR THE LEFT HEADLIGHT)
GB-5 (BEHIND CENTER OF DASH)
GRN/WHT WIRE
GRN/YEL WIRE
HIGH HEADLIGHT RELAY
HOT AT ALL TIMES
J/C
KEY WARNING SWITCH
LEFT FRONT COMBINATION LIGHT
LEFT FRONT FOG LIGHT
LOW HEADLIGHT RELAY
LT GRN/RED WIRE
MAIN FUSE BOX (M/B) (LEFT REAR OF ENGINE COMPT)
MULTI JOINT CONNECTOR
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY HOLDER FUSE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT FOG LIGHT
THROUGH JOINT CONNECTOR
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps & fog lamps circuit (2 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (6 of 9)
AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE (LEFT SIDE OF DASH)
AUTO LEVELER IND LIGHT
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BODY INTEGRATED UNIT (BEHIND CENTER OF DASH)
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMBINATION METER
FRONT VEHICLE HEIGHT SENSOR (LEFT FRONT WHEELWELL)
FUSE 18
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
LEFT HEADLIGHT BEAM LEVELER (BEHIND LEFT HEADLIGHT ASSEMBLY)
MULTI JOINT CONNECTOR
REAR VEHICLE HEIGHT SENSOR (REAR SUSPENSION)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED FUSE, RELAY BOX (F/B) FUSE 5 (BEHIND LEFT SIDE OF DASH)
RIGHT HEADLIGHT BEAM LEVELER (BEHIND RIGHT HEADLIGHT ASSEMBLY)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps leveling circuit -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (7 of 9)
A/C CONTROL PANEL
AUTOMATIC A/C
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
CIRCUIT
CIRCUIT DIMMER DRIVE
CLOCK
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CUP HOLDER
DIMMER CIRCUIT
DRIVE
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-11 (CENTER OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
HAZARD POCKET SWITCH LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR NEEDLE ILLUMINATION LIGHT
JOINT CONNECTOR
JOINT GROUND
LCD ILLUMINATION LIGHT IND
LIGHTING INDICATOR
MANUAL A/C
MICROCOMPUTER
MULTI JOINT CONNECTOR
PLATE ILLUMINATION LIGHT
PNK WIRE
POWER SUPPLY CIRCUIT
SEAT HEATER SWITCH
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT/BLU WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (8 of 9)
2 1 3 PNK WIRE
2.5L TURBO 2.5L
A/C CONTROL PANEL
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER DIODE (RIGHT SIDE OF DASH)
BLOWER FAN SWITCH
BLOWER MOTOR (BEHIND LOWER RIGHT SIDE OF DASH)
BLOWER MOTOR RELAY (RIGHT SIDE OF DASH)
BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH)
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (BEHIND CENTER OF DASH)
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ENGINE CONTROL MODULE (ECM) (UNDER RIGHT SIDE OF DASH)
EVAPORATOR SENSOR (EVAPORATOR CASE ASSEMBLY)
FUSE 22
FUSE 26
FUSE 28 FUSE 27
FUSE 5
GB-10 (CENTER OF DASH)
GB-11 (CENTER OF DASH)
GB-5 (LEFT SIDE OF DASH)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
HOT IN ON OR START FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
INTAKE DOOR ACTUATOR (BEHIND RIGHT SIDE OF DASH)
JOINT
LT GRN WIRE
MULTI JOINT CONNECTOR
OFF
ORG/GRN WIRE
PNK WIRE
PNK/BLU WIRE
PRESSURE SWITCH (LEFT REAR OF ENGINE COMPT)
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
VIO WIRE
VIO/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Manual a/c circuit (1 of 2) -> MULTI JOINT CONNECTOR
multi joint connector wiring diagram (9 of 9)
AT SELECT LEVER
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT (BEHIND CENTER OF DASH)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 12
FUSE 7
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-3 (RIGHT END OF DASH)
GB-4 (CENTER OF DASH)
GB-5 (LEFT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, RELAY FUSE 8 BOX (F/B) (BEHIND LEFT SIDE OF DASH)
HOT AT ALL TIMES MAIN FUSE BOX (M/B) FUSE 14 (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
LT GRN WIRE
MULTI JOINT CONNECTOR
P RANGE SWITCH
RED WIRE
RELAY BLOCK
SHIFT LOCK SOLENOID
STOP, BRAKE SWITCH (UNDER LEFT SIDE OF DASH)
TEST MODE SUB CONNECTOR (LEFT "A" PILLAR)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> MULTI JOINT CONNECTOR
