Subaru Forester SH (2007-2011) fuse 18 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 18, in which he is found in the car Subaru Forester SH (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 18 (1 of 3)
A/T
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COMPASS MIRROR
FUSE 18
FUSE 6
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-6 (CENTER OF DASH)
GRN WIRE
HOT IN ON OR ACC
HOT IN ON OR START
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
M/T
NCA WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic day/night mirror circuit -> FUSE 18
Wiring diagram fuse 18 (2 of 3)
A/T M/T
BACKUP LIGHT
BACKUP LIGHT LEFT REAR COMBINATION LIGHT
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (M/T) (BEHIND CENTER OF DASH)
BRN WIRE
BRN/YEL WIRE
COMPASS MIRROR
FUSE 18
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
MULTI JOINT CONNECTOR
NCA WIRE
POWER DISTRIBUTION SYSTEM
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
TRAILER CONNECTOR
YEL WIRE
Go to component -> Backup lamps circuit -> FUSE 18
Wiring diagram fuse 18 (3 of 3)
AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE (LEFT SIDE OF DASH)
AUTO LEVELER IND LIGHT
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BODY INTEGRATED UNIT (BEHIND CENTER OF DASH)
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMBINATION METER
FRONT VEHICLE HEIGHT SENSOR (LEFT FRONT WHEELWELL)
FUSE 18
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRY WIRE
LEFT HEADLIGHT BEAM LEVELER (BEHIND LEFT HEADLIGHT ASSEMBLY)
MULTI JOINT CONNECTOR
REAR VEHICLE HEIGHT SENSOR (REAR SUSPENSION)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED FUSE, RELAY BOX (F/B) FUSE 5 (BEHIND LEFT SIDE OF DASH)
RIGHT HEADLIGHT BEAM LEVELER (BEHIND RIGHT HEADLIGHT ASSEMBLY)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Headlamps leveling circuit -> FUSE 18
