Subaru Forester SH (2007-2011) front power window sub switch Wiring diagram
This page shows the only wiring diagram for the component.front power window sub switch, which is found in the car Subaru Forester SH (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front power window sub switch (1 of 1)
2.5L TURBO 2.5L
A/F OXYGEN SENSOR RELAY
BATTERY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ WHT WIRE
BLU/RED WIRE
DATA LINK CONNECTOR
DAYTIME RUNNING ELECTRONIC LIGHT THROTTLE RELAY CONTROL RELAY
FRONT POWER WINDOW SUB SWITCH
FUEL PUMP RELAY
FUSE 11
FUSE 12
FUSE 13 FUSE 14
FUSE 15 SBF 7 FUSE GB-6 (CENTER OF DASH)
FUSE 16
FUSE 2
FUSE 3
FUSE 5 SBF 1 FUSE FUSE 1
FUSE 8
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED (OR BLK) WIRE
HIGH HEADLIGHT RELAY
HORN RELAY
IG RELAY MAIN RELAY
J/C
KEY BODY ILLUMI- INTEGRATED NATION UNIT
KEY WARNING SWITCH
LEFT REAR POWER WINDOW SUB SWITCH
LOW HEADLIGHT RELAY
MAIN FAN RELAY 1
MAIN SBF FUSE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
POWER SUNROOF WINDOW MOTOR MAIN ASSEMBLY SWITCH SWITCH
POWER WINDOW RELAY (FUSE, RELAY BLOCK)
REAR DEFOGGER RELAY
RED GRN/ WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY HOLDER
RIGHT REAR POWER WINDOW SUB SWITCH
SBF 3 FUSE SBF 6 FUSE
SBF-2 FUSE
SBF-4 FUSE
SBF-5 FUSE
SBF-9 FUSE
SECONDARY AIR PUMP RELAY
SHORT CONN- ECTOR
STARTER MOTOR
SUB FAN RELAY
TCM (A/T)
THROUGH
TO FUSE, RELAY BOX (F/B) (DIAGRAM
TO FUSE, TO RELAY BOX IGNITION (F/B) SWITCH (DIAGRAM (DIAGRAM
TO POWER TO FUSE, WINDOW RELAY BOX CIRCUIT (F/B) BREAKER (DIAGRAM (DIAGRAM
TO TAIL, ILLUMINATION RELAY (DIAGRAM
TURN SIGNAL, HAZARD MODULE
VDC CONTROL GENERATOR MODULE
W/ REMOTE ENGINE START SYSTEM
W/O REMOTE ENGINE START SYSTEM
WHT RED/ WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 4) -> FRONT POWER WINDOW SUB SWITCH
