Subaru Forester SH (2007-2011) compass mirror Wiring diagrams
This page contains all the electrical diagrams for the component. compass mirror, in which he is found in the car Subaru Forester SH (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
compass mirror wiring diagram (1 of 3)
A/T
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COMPASS MIRROR
FUSE 18
FUSE 6
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-6 (CENTER OF DASH)
GRN WIRE
HOT IN ON OR ACC
HOT IN ON OR START
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
M/T
NCA WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic day/night mirror circuit -> COMPASS MIRROR
compass mirror wiring diagram (2 of 3)
A/T M/T
BACKUP LIGHT
BACKUP LIGHT LEFT REAR COMBINATION LIGHT
BACKUP LIGHT SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY INTEGRATED UNIT (M/T) (BEHIND CENTER OF DASH)
BRN WIRE
BRN/YEL WIRE
COMPASS MIRROR
FUSE 18
FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH)
GB-8 (RIGHT FRONT FLOOR PAN)
GRN WIRE
GRN/BLU WIRE
INHIBITOR SWITCH (RIGHT SIDE OF AUTOMATIC TRANSMISSION)
MULTI JOINT CONNECTOR
NCA WIRE
POWER DISTRIBUTION SYSTEM
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT
TRAILER CONNECTOR
YEL WIRE
Go to component -> Backup lamps circuit -> COMPASS MIRROR
compass mirror wiring diagram (3 of 3)
2.5L
2.5L TURBO 2.5L
AT SELECT LEVER
AUTO HEADLIGHT
BEAM LEVELER CONTROL MODULE (IF EQUIPPED)
BLK WIRE
BLK/BLU WIRE
BLK/YEL (OR BLK) WIRE
BLK/YEL WIRE
BODY INTEGRATED UNIT
BRAKE FLUID LEVEL SWITCH
COMPASS MIRROR
CONTROL UNIT)
CUP HOLDER
FRONT WIPER MOTOR
FUEL PUMP ASSEMBLY
FUEL PUMP CONDENSER
FUEL PUMP CONTROL UNIT (2.5L TURBO)
FUEL PUMP RELAY (2.5L TURBO)
FUSE, RELAY BOX (F/B)
GB-1 (RIGHT FRONT OF ENGINE COMPT)
GB-2 (LEFT FRONT WHEELWELL)
GB-3 (RIGHT SIDE OF DASH) COMBINATION SWITCH
GB-5 (LEFT SIDE OF DASH)
GB-6 (CENTER OF DASH)
GB-7 (RIGHT REAR OF VEHICLE CHASSIS)
GB-8 (RIGHT FRONT FLOOR PAN)
GB-9 (LEFT REAR OF VEHICLE CHASSIS)
GRN/RED (OR BLK) WIRE
GRN/RED WIRE
HIGH MOUNTED STOP LIGHT
HOOD SWITCH WIPER DEICER
IMPACT SENSOR
INHIBITOR SWITCH
KEY LOCK SOLENOID, KEY WARNING SWITCH (A/T)
KEYLESS BUZZER
KEYLESS ENTRY CONTROL MODULE
LEFT FRONT COMBINATION LIGHT
LEFT FRONT DOOR SWITCH
LEFT FRONT FOG LIGHT
LEFT REAR COMBI- NATION LIGHT LEFT POWER SEAT
LEFT REAR DOOR SWITCH
LEFT SEAT BELT SWITCH
LICENSE PLATE LIGHT
LUGGAGE ROOM LIGHT
MAIN FAN MOTOR
MAIN FAN RELAY 2
POWER TRANSISTOR (AUTO A/C)
POWER WINDOW RELAY
PRESSURE SWITCH
REAR ACCE- SSORY POWER SUPPLY SOCKET (CONSOLE) REAR ACCE- SSORY POWER
REAR DEFOGGER
REAR GATE LOCK ACTUATOR, LATCH SWITCH
REAR GATE RELEASE SWITCH
REAR WIPER MOTOR
REMOTE ENGINE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT DOOR SWITCH
RIGHT FRONT FOG LIGHT
RIGHT REAR DOOR SWITCH RIGHT REAR COMBI- NATION LIGHT
ROOM LIGHT
SEAT HEATER RELAY
SEAT HEATER SWITCH
SPOT MAP LIGHT
STEERING ANGLE SENSOR
SUPPLY SOCKET (LUGGAGE ROOM)
TPMS CONTROL MODULE
TRAILER CONNECTOR
TURN SIGNAL, HAZARD MODULE
VDC CONTROL MODULE
VDC OFF SWITCH
W/ O SUNROOF W/ SUNROOF
YAW RATE DELIVERY, LATERAL (TEST) G SENSOR MODE CONNECTOR
YEL/RED WIRE
Go to component -> Ground distribution circuit (1 of 3) -> COMPASS MIRROR
