Subaru Forester SH (2007-2011) auxiliary input terminal Wiring diagram
This page shows the only wiring diagram for the component.auxiliary input terminal, which is found in the car Subaru Forester SH (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary input terminal (1 of 1)
A/C CONTROL PANEL
AUDIO
AUDIO BRACKET GROUND (W/O NAVIGATION)
AUXILIARY INPUT TERMINAL
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER FAN SWITCH (MANUAL A/C)
BODY INTEGRATED UNIT
CLOCK
COMBINATION METER
CRANKSHAFT POSITION SENSOR SHIELD
ECM (2.5L TURBO)
ELECTRONIC THROTTLE CONTROL SHIELD KNOCK SENSOR SHIELD
FRONT ACCESSORY POWER SUPPLY SOCKET
FUSE, RELAY BOX (F/B)
GB-10 (CENTER OF DASH)
GB-11 (CENTER OF DASH)
GE (LEFT SIDE OF ENGINE ASSEMBLY)
HAZARD SWITCH
JOINT GROUND CONNECTOR
LEFT OUTER MIRROR ASSEMBLY
LEFT SECONDARY AIR COMBINATION VALVE RIGHT SECONDARY AIR COMBINATION VALVE
MANUAL A/C AUTOMATIC A/C
NAVIGATION UNIT
NCA WIRE
PASSENGERS DOOR LOCK SWITCH
POWER WINDOW MAIN SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT OUTER MIRROR ASSEMBLY
SIDE OF DASH)
W/ NAVIGATION
W/O MIRROR HEATER
W/O NAVIGATION
Go to component -> Ground distribution circuit (2 of 3) -> AUXILIARY INPUT TERMINAL
