Car Wiring Diagrams for Forced entry circuit for Subaru Forester SG facelift (2005-2008)

ANTI-THEFT SYSTEM BLK WIRE BLK/GRN WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE COMBINATION METER FUSE 18 FUSE 2 FUSE 3 FUSE 6 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GB-1 (AT LEFT KICK PANEL) GB-3 (AT RIGHT KICK PANEL) GRN WIRE GRN/BLK WIRE GRY/BLK WIRE HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IND DOOR KEYLESS BUZZER (AT CENTER FRONT OF ENGINE COMPT) KEYLESS ENTRY CONTROL MODULE (BEHIND RIGHT END OF DASH) LEFT DOOR LOCK SWITCH LEFT FRONT DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR) LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR) LEFT REAR DOOR SWITCH (AT REAR OF LEFT REAR DOOR) LT GRN WIRE LT GRN/BLK WIRE MAIN FUSE BOX (M/B) (AT LEFT SIDE OF ENGINE COMPT) ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE REAR GATE LATCH SWITCH (AT LOWER CENTER OF REAR GATE) REAR GATE LOCK ACTUATOR RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR) RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR) RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR SWITCH WARNING SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
