Subaru Forester SG facelift (2005-2008) vdc operation indicator light Wiring diagram
This page shows the only wiring diagram for the component.vdc operation indicator light, which is found in the car Subaru Forester SG facelift (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vdc operation indicator light (1 of 1)
ABS WARNING LIGHT IND
BLK WIRE
BLU WIRE
BRAKE FLUID WARNING INDICATOR LIGHT
BRN WIRE
BRN/YEL WIRE
CAN JOINT CONNECTOR
COMBINATION METER
FUSE 14
FUSE 18
FUSE 8
FUSE, RELAY BOX (BEHIND LEFT
GB-1 (AT LEFT KICK PANEL)
GB-3 (AT RIGHT KICK PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT ABS WHEEL SPEED SENSOR (AT RIGHT REAR OF ENGINE COMPT)
LEFT REAR ABS WHEEL SPEED SENSOR (AT LEFT REAR WHEEL HUB ASSEMBLY)
LT GRN/YEL WIRE
NCA WIRE
ORG/WHT WIRE
RED WIRE
RED/YEL WIRE
RIGHT FRONT ABS WHEEL SPEED SENSOR (AT RIGHT REAR OF ENGINE COMPT)
RIGHT REAR ABS WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL HUB ASSEMBLY)
SBF HOLDER (ON LEFT SIDE OF ENGINE COMPT)
SBF-7 FUSE
SIDE OF DASH)
STEERING ANGLE SENSOR (BEHIND LEFT SIDE OF DASH)
VDC OFF SWITCH
VDC OPERATION INDICATOR LIGHT
VDC SHIELD J/C (BEHIND RIGHT
VDC WARNING LIGHT IND
VIO WIRE
WHT WIRE
WHT/RED WIRE
YAW RATE, LATERAL G SENSOR
YEL WIRE
Go to component -> Anti-lock brakes circuit, with vdc (2 of 2) -> VDC OPERATION INDICATOR LIGHT
