Subaru Forester SG facelift (2005-2008) combination switch Wiring diagrams
This page contains all the electrical diagrams for the component. combination switch, in which he is found in the car Subaru Forester SG facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram combination switch (1 of 6)
1 2 W/O HID HEADLAMPS W/ HID HEADLAMPS
3 4 W/O HEATED MIRRORS W/ HEATED MIRRORS
BACK- UP LIGHT TURN SIGNAL LIGHT
BACK-UP LAMPS CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
FUSE 16
FUSE 2
FUSE 5
FUSE 6
FUSE 7
FUSE SBF-2
FUSE, RELAY BOX (BEHIND LEFT SIDE OF DASH) FUSE 5
GB-3 (AT RIGHT KICK PANEL)
GR-2
GRN WIRE
GRN/WHT WIRE
GROUND JOINT CONNECTOR (AT RIGHT REAR 1 1 CORNER OF VEHICLE)
HAZARD SWITCH
HEAD PARK
HEADLIGHTS SYSTEM (W/ HID)
HID RELAY
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY (UNDER LEFT SIDE OF DASH, ON RELAY BLOCK)
LEFT FRONT CLEARANCE LIGHT
LEFT OUTER MIRROR TURN SIGNAL LIGHT GF-1 (BEHIND RIGHT SIDE OF FRONT BUMPER)
LEFT REAR COMBINATION LIGHT
LEFT TURN IND
LICENSE PLATE LIGHT
LIGHTING SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OFF
OFF ON
OFF ON OFF
ON OFF
ORG/ WIRE
ORG/BLK WIRE
PARKING SWITCH
RED WIRE
RED/YEL WIRE
RIGHT FRONT CLEARANCE LIGHT LEFT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL LIGHT
RIGHT OUTER MIRROR TURN SIGNAL LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT
RIGHT TURN IND
STOP LIGHT SWITCH (UNDER LEFT SIDE OF DASH)
STOP LIGHT TAIL LIGHT
TAIL LIGHT STOP LIGHT
TAIL, ILLUM- INATION RELAY
TRAILER CONNECTOR (AT RIGHT REAR CORNER OF VEHICLE)
TURN SIGNAL SWITCH
TURN SIGNAL, HAZARD MODULE (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> COMBINATION SWITCH
Wiring diagram combination switch (2 of 6)
BLK WIRE
BLK/BLU WIRE
COMBINATION SWITCH
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL) LO HIGH
FRONT WIPER SWITCH
FUSE 15
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GB-3 (AT RIGHT KICK PANEL)
GRN/YEL WIRE
HI HI OFF INT LO LO
HOT IN ACC OR ON
INTERMITTENT WIPER MODULE
LT GRN/RED WIRE
MIST SWITCH MIST
NCA WIRE
OFF
OFF HI INT LO
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WIPER MOTOR PARK
YEL WIRE
YEL/BLK WIRE
Go to component -> Front wiper/washer circuit -> COMBINATION SWITCH
Wiring diagram combination switch (3 of 6)
A/T
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
COMBINATION METER
COMBINATION SWITCH
COMBINATION SWITCH (PARKING SWITCH)
DAYTIME RUNNING LIGHT CONTROL MODULE (BEHIND RIGHT SIDE DASH)
DAYTIME RUNNING LIGHT RELAY (BEHIND RIGHT SIDE OF DASH)
DIODE (DAYTIME RUNNING LIGHT) (BEHIND RIGHT SIDE OF DASH)
DIODE (FRONT FOGLIGHT) (BEHIND CENTER OF DASH)
FRONT FOGLIGHT RELAY (UNDER LEFT SIDE
FRONT FOGLIGHT SWITCH
FUSE 14
FUSE 18
FUSE 7
FUSE 8
FUSE 9
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GB-1 (AT LEFT KICK PANEL)
GB-3 (AT RIGHT KICK PANEL)
GB-3 (AT RIGHT KICK PANEL) HI HID
GB-3 (AT RIGHT KICK PANEL) INHIBITOR SWITCH
GENERATOR
GF-2 (BEHIND LEFT SIDE OF FRONT BUMPER) GF-1 (BEHIND RIGHT SIDE OF FRONT BUMPER)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HI HI LO PASS
HI HID
HI-BEAM IND
HID DIODE (BEHIND RIGHT SIDE OF DASH)
HID RELAY (BEHIND LEFT SIDE OF DASH)
HIGH BEAM RELAY (BEHIND RIGHT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT RELAY
LIGHTING SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (M/B) (AT LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OF DASH, ON RELAY BLOCK)
OFF
OFF ON ON
ON OFF
ORG/ WIRE
PARK HEAD OFF
PARKING BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER)
PASS LO DIMMER, PASSING SWITCH
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT RELAY
STARTING/CHARGING SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Headlamps circuit, with high intensity discharge -> COMBINATION SWITCH
Wiring diagram combination switch (4 of 6)
A/T
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
COMBINATION METER
COMBINATION SWITCH
DAYTIME RUNNING LIGHT CONTROL MODULE (BEHIND RIGHT SIDE DASH)
DAYTIME RUNNING LIGHT RELAY (BEHIND RIGHT SIDE OF DASH)
DIODE (DAYTIME RUNNING LIGHT) (BEHIND RIGHT SIDE OF DASH)
DIODE (FRONT FOGLIGHT) (BEHIND CENTER OF DASH)
FRONT FOGLIGHT RELAY (UNDER LEFT SIDE
FRONT FOGLIGHT SWITCH
FUSE 14
FUSE 18
FUSE 7
FUSE 8
FUSE 9
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GB-1 (AT LEFT KICK PANEL)
GB-3 (AT RIGHT KICK PANEL)
GENERATOR
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HI-BEAM IND
HIGH BEAM RELAY (BEHIND RIGHT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ON OR START
INHIBITOR SWITCH
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT RELAY
LO PASS
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (M/B) (AT LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OF DASH, ON RELAY BLOCK)
ON OFF
ORG/ WIRE
PARK HEAD OFF PASS LO DIMMER, PASSING SWITCH LIGHTING SWITCH
PARKING BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RESISTOR (DAYTIME RUNNING LIGHT) (AT RIGHT SIDE OF ENGINE COMPT)
RIGHT FRONT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT RELAY
STARTING/CHARGING SYSTEM
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Headlamps circuit, without high intensity discharge -> COMBINATION SWITCH
Wiring diagram combination switch (5 of 6)
AT SELECT LEVER ILLUMINATION LIGHT
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BLU/RED WIRE
BODY INTEGRATED MODULE (BEHIND LEFT SIDE OF DASH)
CLOCK
COMBINATION METER
COMBINATION SWITCH
COMPACT DISC PLAYER RELAY ILLUMINATION LIGHT
DIMMER
ENGINE CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
FRONT ACCESSORY POWER SUPPLY SOCKET ILLUMINATION LIGHT
FRONT FOGLIGHT SWITCH ILLUMINATION LIGHT
FUSE 12
FUSE 14
FUSE 2
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HAZARD SWITCH ILLUMINATION LIGHT
HEAD OFF PARK
HEADLIGHT LEVELER SWITCH ILLUMINATION (W/ HID)
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION LIGHTS
KEY ILLUMINATION LIGHT
LIGHTING SWITCH
LT GRN WIRE
MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) FUSE 7
MANUAL A/C CONTROL MODULE ILLUMINATION
NCA WIRE
ODO/TRIP OUT TEMP LCD BACKLIGHT
ORG/ WIRE
ORG/WHT WIRE
RADIO ILLUMINATION LIGHT
RED WIRE
TAIL, ILLUMINATION RELAY
VDC OFF SWITCH
VIO WIRE
WHT WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Instrument illumination circuit -> COMBINATION SWITCH
Wiring diagram combination switch (6 of 6)
2.5L
A/C FAN RELAY 1 RELAY HOLDER (ON LEFT SIDE OF ENGINE COMPT)
A/F OXYGEN SENSOR RELAY
ABC CONTROL MODULE VDC HYDRAULIC UNIT
BLK WIRE
BLU WIRE
CLOCK
COMBINATION METER
COMBINATION SWITCH
COMPASS MIRROR DAYTIME RUNNING LIGHT RELAY
FAN RELAY 2
FROM MAIN FUSE BOX (FUSE SBF-1) (DIAGRAM 1 OF 4)
FROM MAIN FUSE BOX, HEADLIGHT RELAYS (DIAGRAM 1 OF 4)
FRONT WIPER MOTOR FRONT WASHER MOTOR REAR WIPER MOTOR
FRONT WIPER SWITCH
FUSE 14
FUSE 15
FUSE 9
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GENERATOR
GRN WIRE
IGNITION SWITCH
INTERRUPT RELAY
LOCK
MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
NCA WIRE
RADIO
REAR WIPER INTERMITTENT UNIT REAR WASHER MOTOR
RED WIRE
RELAY BLOCK (BEHIND RIGHT SIDE OF DASH) FUSE
RUN WIRE
SBF HOLDER (ON LEFT SIDE OF ENGINE COMPT) SBF-7 FUSE
SBF-2 FUSE
SBF-4 FUSE
SBF-8 FUSE
TO FUSE, RELAY BOX
TO FUSE, RELAY BOX (DIAGRAM 3 OF 4)
TO FUSE, RELAY BOX (FUSE 4) (DIAGRAM 3 OF 4)
TO IGNITION RELAY (DIAGRAM 3 OF 4)
W/ HID
W/ SECURITY SYSTEM
W/O VDC W/ VDC
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (2 of 4) -> COMBINATION SWITCH
