Car Wiring Diagrams for Heated seats circuit for Subaru Forester SG (2002-2005)

ACCESSORY RELAY (BEHIND LEFT SIDE OF DASH, ON RELAY BLOCK) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE FUSE FUSE 4 FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH) GB-1 (AT LEFT KICK PANEL) GR-1 (UNDER RIGHT FRONT SEAT) HIGH OFF LOW HOT AT ALL TIMES HOT IN ACC OR ON LEFT SEAT HEATER LEFT SEAT HEATER SWITCH LT GRN WIRE RED WIRE RED/BLU WIRE RIGHT SEAT HEATER RIGHT SEAT HEATER SWITCH WHT WIRE YEL WIRE YEL/BLK WIRE
