Subaru Forester SG (2002-2005) light switch head park Wiring diagram
This page shows the only wiring diagram for the component.light switch head park, which is found in the car Subaru Forester SG (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light switch head park (1 of 1)
BACK- UP LIGHT TURN SIGNAL LIGHT
BACK- UP LIGHT TURN SIGNAL LIGHT TAIL LIGHT
BACK-UP LAMPS CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
FUSE 16
FUSE 5
FUSE 6
FUSE 7
FUSE, RELAY BOX (BEHIND LEFT SIDE OF DASH) FUSE 5
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GB-3 (AT RIGHT KICK PANEL)
GRN WIRE
GRN/WHT WIRE
GROUND JUNCTION CONNECTOR
HAZARD SWITCH
HIGH MOUNT STOPLIGHT
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY (BEHIND LEFT SIDE OF DASH)
LEFT FRONT CLEARANCE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL LIGHT
LEFT TURN IND
LICENSE PLATE LIGHT
LIGHT SWITCH HEAD PARK
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OFF
OFF ON
ON OFF
ON OFF ON
ORG/ WIRE
PARKING SWITCH
RED WIRE
RED/YEL WIRE
RIGHT FRONT CLEARANCE LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TURN IND
SBF-2 FUSE
STOP LIGHT
STOP LIGHT TAIL LIGHT
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
TAIL, ILLUMINATION RELAY
TRAILER CONNECTOR
TURN SIGNAL SWITCH
TURN SIGNAL, HAZARD MODULE
VIO WIRE
W/ CRUISE CONTROL MODEL
W/O CRUISE CONTROL MODEL GF-1 (BEHIND RIGHT SIDE OF FRONT BUMPER)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LIGHT SWITCH HEAD PARK
