Subaru Forester SF (1997-2000) fuse/ relay box Wiring diagrams

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE FUSE 19 FUSE 4 FUSE/ RELAY BOX HIGH OFF LOW HOT AT ALL TIMES HOT IN ACC, ON LEFT SEAT HEATER LEFT SEAT HEATER SWITCH LT GRN WIRE REAR ACCESSORY POWER SUPPLY RED WIRE RED/BLU WIRE RIGHT SEAT HEATER RIGHT SEAT HEATER SWITCH SEAT HEATER/ REAR ACCESSORY POWER SUPPLY RELAY (LEFT SIDE OF DASH) WHT WIRE YEL WIRE YEL/RED WIRE

A/T A/T M/T A/T SHIFT LOCK CONTROL MODULE ABS CONTROL MODULE AIR CONDITIONING RELAY HOLDER BLK WIRE BLK/WHT WIRE BLU WIRE CLOCK COMBINATION SWITCH ENGINE CONTROL MODULE FROM MAIN FUSE BOX HEADLIGHT RELAYS (DIAGRAM 1 OF 3) FROM MAIN FUSE BOX SBF-1 (DIAGRAM 1 OF 3) FRONT ACCESSORY POWER SUPPLY FRONT WASHER MOTOR FRONT WIPER MOTOR FRONT WIPER/ WASHER SWITCH FUSE 10 FUSE 15 FUSE 16 FUSE 19 FUSE 4 FUSE 9 FUSE/ RELAY BOX GENERATOR GRN WIRE GRN/BLK WIRE IGNITION RELAY IGNITION SWITCH INHIBITOR SWITCH M/T MAIN FAN RELAY MAIN FUSE BOX NCA WIRE NEUTRAL POSITION SWITCH NOT USED NOT USED OFF OFF ON RADIO REAR ACCESSORY POWER SUPPLY REAR WASHER MOTOR REAR WIPER RELAY REAR WIPER MOTOR RED WIRE REMOTE CONTROL REARVIEW MIRROR SWITCH SBF HOLDER SBF-2 FUSE SBF-4 FUSE SBF-7 FUSE SEAT HEATER SWITCHES SEAT HEATER/ REAR ACCESSORY POWER SUPPLY RELAY (LEFT SIDE OF DASH) STARTER INTERLOCK RELAY STOP, BRAKE SWITCH (W/ CRUISE) STOPLIGHT SWITCH (W/O CRUISE) SUB FAN RELAY TO FUSE, RELAY BOX FUSE 14 (DIAGRAM 3 OF 3) TO FUSE, RELAY BOX FUSE 18 (DIAGRAM 3 OF 3) WHT WIRE WHT/BLK WIRE YEL WIRE

A/T SELECTOR LEVER ILLUMINATION LIGHT A/T SHIFT LOCK CONTROL MODULE ABS CONTROL MODULE AIR CONDITIONING RELAY HOLDER AIRBAG CONTROL MODULE BACK-UP LIGHT SWITCH (M/T) BLK WIRE BLOWER MOTOR RELAY CD ILLUMINATION LIGHT COMBINATION METER COMPRESSOR) CRUISE CONTROL MAIN SWITCH CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT ASHTRAY ILLUMINATION LIGHT CRUISE CONTROL MODULE ENGINE CONTROL MODULE FROM FUSE/RELAY BOX FROM IGNITION SWITCH (DIAGRAM 2 OF 3) FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT FUEL PUMP RELAY FUSE 11 FUSE 12 FUSE 14 FUSE 17 FUSE 18 FUSE 6 FUSE/ RELAY BOX GRN WIRE HAZARD SWITCH ILLUMINATION LIGHT IGNITION COIL ILLUMINATION CONTROL MODULE INHIBITOR SWITCH (A/T) KEYLESS ENTRY CONNECTOR MAIN FAN RELAY MIRROR HEATER RELAY MODE CONTROL PANEL MODE CONTROL PANEL ILLUMINATION LIGHT ORG/ WIRE PARKING SWITCH RADIO ILLUMINATION LIGHT REAR DEFOGGER RELAY REAR DEFOGGER SWITCH REAR DEFOGGER SWITCH ILLUMINATION LIGHT RED WIRE SUB FAN RELAY AIR CONDITIONING RELAY TAIL, ILLUMINATION RELAY THERMAL PROTECTOR TRANSMISSION CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE DOOR LOCK TIMER (LEFT SIDE OF DASH) FUSE 18 FUSE 3 FUSE 7 FUSE/ RELAY BOX GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON AND START KEYLESS ENTRY CONNECTOR (LEFT SIDE OF DASH) LEFT DOOR LOCK SWITCH LEFT FRONT DOOR LOCK ACTUATOR LT GRN WIRE LT GRN/BLK WIRE LT LT MAIN FUSE BOX REAR GATE LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR VIO WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE CHANGE OVER SWITCH DEFOGGER SYSTEM FUSE 4 FUSE/ RELAY BOX GRN WIRE HOT IN ACC, ON LEFT REAR VIEW MIRROR LEFT/ RIGHT MOTOR MIRROR HEATER MIRROR HEATER SWITCH ON OFF RED WIRE REMOTE CONTROL REARVIEW MIRROR SWITCH RIGHT REAR VIEW MIRROR UP/ DOWN MOTOR WHT WIRE YEL WIRE

AUDIO GROUND BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE FUSE 2 FUSE 9 FUSE/ RELAY BOX GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ACC, ON LEFT FRONT DOOR SPEAKER LEFT FRONT TWEETER LEFT REAR DOOR SPEAKER MAIN FUSE BOX NOISE KILLER (1999) (LEFT SIDE OF DASH) ORG/WHT WIRE RADIO (LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT TWEETER RIGHT REAR DOOR SPEAKER VIO WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE COMBINATION SWITCH FUSE 15 FUSE/ RELAY BOX GRN WIRE GRN/RED WIRE GRN/YEL WIRE HOT IN ACCY, ON LT GRN WIRE OFF PARK REAR WASHER MOTOR (WASHER RESERVOIR) REAR WIPER MOTOR REAR WIPER RELAY (ON RIGHT REAR OF CARGO AREA) REAR WIPER/ WASHER SWITCH RED WIRE RUN WIRE WASH ON WASH ON FRONT WIPER/ WASHER CIRCUIT WHT WIRE WIPER MOTOR YEL WIRE YEL/BLK WIRE

A/T SHIFT LOCK CONTROL MODULE (BEHIND LEFT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE FUSE 16 FUSE 18 FUSE 4 FUSE/ RELAY BOX GRN WIRE GRN/BLK WIRE GRN/RED WIRE HOT AT ALL TIMES HOT AT ALL TIMES MAIN FUSE BOX FUSE 6 HOT IN ACCY AND ON HOT IN ON AND START INHIBITOR SWITCH (ON RIGHT SIDE OF TRANSMISSION) KEY LOCK SOLENOID (BEHIND IGNITION KEY CYLINDER) KEY WARNING SWITCH (PART OF IGNITION SWITCH) PARK POSITION SWITCH (AT BASE OF SHIFT LEVER) RED WIRE SHIFT LOCK SOLENOID (AT BASE OF SHIFT LEVER) STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

2 1 DIAGNOSIS CONNECTOR (BEHIND LEFT SIDE OF DASH) 7 3 6 2 CHECK CONNECTOR (UNDER LEFT SIDE OF DASH) AIRBAG CIRCUIT AIRBAG CONTROL MODULE (AHEAD OF FRONT FLOOR TUNNEL) BLK WIRE BLK/WHT WIRE BLU WIRE COMBINATION METER DRIVER SIDE INFLATOR FUSE 11 FUSE 5 FUSE 6 FUSE/ RELAY BOX GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON AND START IGNITION RELAY (BEHIND LEFT SIDE OF DASH) IGNITION SWITCH LT GRN WIRE MAIN FUSE BOX OFF PASSENGER SIDE INFLATOR RED WIRE RED/BLK WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
