Tire pressure monitoring circuit, w/ hev for Subaru Crosstrek I facelift (2015-2017)
Tire pressure monitoring circuit, w/ hev
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN/WHT WIRE
CAN TRANSCEIVER, RECEIVER
CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FUSE 4
FUSE 5
FUSE 7
FUSE, RELAY BOX (F/B)
GB-11
GB-9
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ IG 2 RELAY ENERGIZED
MICRO COMPUTER
POWER
RED WIRE
SUPPLY
TIRE INFLATION PRESSURE WARNING LIGHT IND
TPMS CONTROL MODULE
WHT WIRE
WHT/BLU WIRE
