Subaru Crosstrek I facelift (2015-2017) driver side relay holder ig relay 2 Wiring diagram
This page shows the only wiring diagram for the component.driver side relay holder ig relay 2, which is found in the car Subaru Crosstrek I facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side relay holder ig relay 2 (1 of 1)
ACCESSORY RELAY
ACTIVE GRILLE SHUTTER
AIR BAG CONTROL MODULE
AT SELECT LEVER
AUTO HEAD- LIGHT BEAM LEVELER CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/YEL WIRE
BODY INTEGRATED UNIT
BRAKE FLUID LEVEL SWITCH
BRAKE STROKE SENSOR SHIELD
COMBINATION SWITCH
DRIVER SIDE RELAY HOLDER IG RELAY 2
ENGINE COMPARTMENT RELAY HOLDER
FRONT WIPER MOTOR
FUSE, RELAY BOX (F/B)
GAP-
GB-1
GB-2
GB-3
GB-4
GB-5
GB-6
GRN WIRE
GRN/RED WIRE
HOOD SWITCH
HPCM
ID CODE BOX
IG RELAY 1
IMPACT SENSOR
INHIBITOR SWITCH
KEYLESS ACCESS CONTROL MODULE
KEYLESS BUZZER
LEFT FRONT COMBINATION LIGHT
LEFT FRONT FOG LIGHT
LEFT HI-BEAM
MAIN FAN MOTOR
MAIN FAN RELAY 2
NCA WIRE
OUTPUT CLUTCH RELAY
PADDLE SHIFT SWITCH
PASSENGER SIDE RELAY HOLDER
POWER STEERING CONTROL MODULE
POWER TRANSISTOR
POWER WINDOW RELAY
PRESSURE SWITCH
REAR VIEW MIRROR)
RED WIRE
REMOTE ENGINE START CONTROL MODULE
RIGHT END OF DASH)
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT FOG LIGHT
RIGHT HI-BEAM
ROLL CONNECTOR
ROOM LIGHT
SEAT HEATER RELAY
SECURITY CONTROL MODULE
SHIELD
SPOT MAP LIGHT
STARTER RELAY
STEERING ANGLE SENSOR
STEERING LOCK CONTROL MODULE
SUNROOF MOTOR ASSEMBLY,
TELEMATICS BUTTON
TURN SIGNAL LIGHT, HAZARD MODULE
TURN SIGNAL SWITCH
VDC CONTROL MODULE
W/ ID CODE BOX
WASHER FLUID LEVEL SENSOR
WIPER DEICER
WIPER RELAY
YEL WIRE
Go to component -> Ground distribution circuit, w/ hev (1 of 3) -> DRIVER SIDE RELAY HOLDER IG RELAY 2
