Wiring diagram engine performance 2.0l hybrid, engine controls circuit for Subaru Crosstrek GT facelift (2020-2022)

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (1 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (1 of 7)

Get access

ACTIVE GRILLE SHUTTER ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DOOR LOCKS SYSTEM FUSE 11 FUSE 19 FUSE 36 FUSE, RELAY BOX (F/B) GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) MASS AIR FLOW/ INTAKE AIR TEMPERATURE SENSOR PNK WIRE PNK/BLK WIRE REAR OXYGEN SENSOR RED WIRE SHIELD STOP LIGHT, BRAKE SWITCH WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (2 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (2 of 7)

Get access

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE DELIVERY MODE FUSE 39 FUEL LEVEL SENSOR FUEL PUMP FUEL PUMP RELAY FUSE 14 FUSE 15 FUSE 5 FUSE, RELAY BOX (F/B) GB-8 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG 2 RELAY ENERGIZED INSTRUMENT CLUSTER SYSTEM LEAK CHECK VALVE ASSEMBLY (UNDER LEFT REAR OF VEHICLE) LT BLU WIRE LT GRN WIRE MAIN FUSE BOX (M/B) N/A PNK WIRE PRESSURE SENSOR RED WIRE RED/BLK WIRE SHIELD SWITCHING VALVE VACUUM PUMP WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (3 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (3 of 7)

Get access

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE ECM (LEFT SIDE OF ENGINE COMPT) ELECTRIC VENT SOLENOID VALVE FUEL TANK PRESSURE SENSOR FUSE 21 FUSE 22 FUSE 23 FUSE 26 FUSE 27 GE-1 GRN WIRE HIGH PRESSURE FUEL PUMP HOT AT ALL TIMES LEFT TUMBLE GENERATOR VALVE ACTUATOR LT GRN WIRE MAIN FUSE BOX (M/B) MAIN RELAY ORG/ WIRE PNK WIRE RED WIRE VIO WIRE WHT WIRE YEL WIRE YEL/RED WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (4 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (4 of 7)

Get access

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE CAN TRANSCEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM ECO GAUGE (NORMAL METER) GB-6 GRN WIRE GRN/WHT WIRE IGN IND LEFT EXHAUST OIL CONTROL SOLENOID LEFT INTAKE OIL CONTROL SOLENOID MALFUNCTION MICROCOMPUTER OIL PRESSURE OIL PRESSURE SWITCH PNK WIRE RED WIRE RIGHT EXHAUST OIL CONTROL SOLENOID RIGHT INTAKE OIL CONTROL SOLENOID SHIFT REGISTER TACHOMETER WHT WIRE YEL/RED WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (5 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (5 of 7)

Get access

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BRN/WHT WIRE BRN/YEL WIRE ENGINE COOLANT TEMPERATURE SENSOR FUEL PRESSURE SENSOR GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE LEFT EXHAUST CAMSHAFT POSITION SENSOR LEFT INTAKE CAMSHAFT POSITION SENSOR MANIFOLD ABSOLUTE PRESSURE SENSOR ORG/ WIRE RED WIRE RIGHT EXHAUST CAMSHAFT POSITION SENSOR RIGHT INTAKE CAMSHAFT POSITION SENSOR RIGHT TUMBLE GENERATOR VALVE ACTUATOR WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (6 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (6 of 7)

Get access

BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN/WHT WIRE BRN/YEL WIRE CRANKSHAFT POSITION SENSOR ECM (LEFT SIDE OF ENGINE COMPT) FRONT OXYGEN (A/F) SENSOR FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE ORG/ WIRE PNK WIRE RED WIRE SHIELD WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

Wiring diagram engine performance 2.0l hybrid, engine controls circuit (7 of 7)

Crosstrek Subaru GT facelift (2020-2022): Wiring diagram engine performance 2.0l hybrid, engine controls circuit (7 of 7)

Get access

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE EGR CONTROL VALVE EGR TEMPERATURE SENSOR ELECTRONIC THROTTLE CONTROL ENGINE OIL TEMPERATURE SENSOR GE-1 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HYBRID CONTROL CIRCUIT IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 KNOCK SENSOR #2 KNOCK SENSOR 1 OIL LEVEL SWITCH PNK WIRE PURGE CONTROL SOLENOID VALVE RED WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
