Forced entry circuit, hybrid for Subaru Crosstrek GT facelift (2020-2022)

Forced entry circuit, hybrid (1 of 5)

Crosstrek Subaru GT facelift (2020-2022): Forced entry circuit, hybrid (1 of 5)

Get access

AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM BLK WIRE BLU WIRE BRN WIRE DOOR LOCK BACKUP UNIT FUSE 13 FUSE 14 FUSE 33 FUSE 36 FUSE, RELAY BOX (F/B) GB-4 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED ID CODE BOX (IF EQUIPPED) KEYLESS ACCESS CONTROL MODULE LT GRN WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR LOCK ACTUATOR STEERING LOCK CONTROL MODULE VIO WIRE W/ ID CODE BOX W/O ID CODE BOX WHT WIRE YEL WIRE

Forced entry circuit, hybrid (2 of 5)

Crosstrek Subaru GT facelift (2020-2022): Forced entry circuit, hybrid (2 of 5)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 13 GB-6 GB-7 GB-9 GRN WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LT GRN WIRE MAIN FUSE BOX (M/B) ORG/ WIRE PNK WIRE RED WIRE RED/YEL WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH VIO WIRE W/ ID CODE BOX W/O ID CODE BOX WHT WIRE YEL WIRE

Forced entry circuit, hybrid (3 of 5)

Crosstrek Subaru GT facelift (2020-2022): Forced entry circuit, hybrid (3 of 5)

Get access

BLK WIRE BLU WIRE BLU/BLK WIRE BODY INTEGRATED UNIT BRN WIRE COMPUTER DATA LINES SYSTEM CVT FRONT LOCK RELAY FRONT UNLOCK RELAY FUSE, RELAY BOX (F/B) (LEFT END OF DASH) GB-4 GREEN GRN WIRE GRN/WHT WIRE ILLUMINATION INDICATOR KEYLESS BUZZER LEFT REAR DOOR LOCK ACTUATOR LT GRN WIRE ORG/ WIRE P RANGE SWITCH PNK WIRE PUSH BUTTON IGNITION SWITCH REAR GATE UNLOCK RELAY RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR DOOR LOCK ACTUATOR VIO WIRE WHT WIRE YEL WIRE YELLOW)

Forced entry circuit, hybrid (4 of 5)

Crosstrek Subaru GT facelift (2020-2022): Forced entry circuit, hybrid (4 of 5)

Get access

ACCESS KEY IND BLK WIRE BLU WIRE BRN WIRE CAN TRANSCEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT GB-4 GB-6 GB-7 GRN WIRE HOOD SWITCH IGN LOCK LT GRN WIRE MICRO COMPUTER PASSENGERS DOOR LOCK SWITCH PNK WIRE REAR GATE LOCK ACTUATOR, LATCH SWITCH REAR GATE OPENER, LOCK BUTTON RED WIRE RED/BLU WIRE REMOTE CONTROL MIRROR SWITCH (DOOR LOCK SWITCH) SECURITY IND SHIFT REGISTER SPEAKER UNLOCK VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE

Forced entry circuit, hybrid (5 of 5)

Crosstrek Subaru GT facelift (2020-2022): Forced entry circuit, hybrid (5 of 5)

Get access

BLK WIRE BLU WIRE BRN WIRE CENTER KEYLESS ACCESS INTERIOR ANTENNA COMPUTER DATA LINES SYSTEM FRONT KEYLESS ACCESS INTERIOR ANTENNA FUSE 15 FUSE, RELAY BOX (F/B) GB-4 GRN WIRE GRY WIRE HOT W/ IG 2 RELAY ENERGIZED INLET DOOR ASSY-CHARGING ANTENNA KEYLESS ACCESS CONTROL MODULE LEFT OUTER HANDLE ORG/ WIRE PNK WIRE REAR GATE KEYLESS ACCESS EXTERIOR ANTENNA REAR KEYLESS ACCESS INTERIOR ANTENNA RED WIRE RIGHT END OF DASH) RIGHT OUTER HANDLE VIO WIRE WHT WIRE YEL WIRE
