Electronic power steering circuit for Subaru BRZ ZC (2012-2016)

1 2 3 4 5 6 7 8 9 10 11 12 CANH 1 2 PIG PGND BLK WIRE BLK/YEL WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CAN DRIVER CIRCUIT COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ENGINE ROOM RELAY EPS FUSE BLOCK, JUNCTION BLOCK (RIGHT FRONT OF ENGINE COMPT) FUSE GAUGE FUSE GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES IG+ CANL INSTRUMENT PANEL JUNCTION BLOCK (LEFT END OF DASH) LED DRIVER MPX-B FUSE PNK WIRE POWER POWER STEERING ECU (ON STEERING COLUMN) POWER STEERING IND POWER STEERING MOTOR RED/WHT WIRE RELAY ENERGIZED RESOLVER RZCS RZSN RZG RZV STEERING COLUMN ASSEMBLY STEERING SENSOR (TOP OF STEERING COLUMN) TORQUE SENSOR WHT WIRE WHT/GRN WIRE
